With Our CO2 laser power supply, the CO2 laser tube may have many advantages: stable performance in frequency,easy to light.EFR PS-X series of high-frequency CO2 laser power supply is the high-efficient, high-frequency, high-speed CO2 laser supporting power supply developed by our company. It has several advantages such as small size, light weight, easy to operate, good compatibility with the CO2 laser tube.
Laser Power Supply Model PS-80W Technical Parameter.
Input Voltage |
Input Voltage |
AC220V or AC110V |
|
AC Frequency |
47-440Hz |
||
Cold surge current |
≤60A(AC220V input) |
≤60A(AC220V input) |
|
Leak current |
≤0.7mA(AC220V input) |
≤0.7mA(AC220V input) |
|
Output |
Max output Voltage |
DC 40KV |
|
|
Max Output current |
DC 28mA |
|
Efficiency |
when>92%load down |
||
Time no-failure |
>10000 hours |
||
Response speed |
≤1ms(the time from output of switch signal to 90%of initial setting current) |
||
Control port |
TTL electricity level switch control, valid electricity has high/low level choices |
||
