Help CenterCO2 Laser Power Source 60W
Related Products
Specifications
CO2 laser power source 60W -150W.Laser power source has good compatibility and a perfect protection of opening circuit.
CO2 Laser Power Source Model PS-60 Technical Parameters
Input Voltage |
Input Voltage |
AC220V or AC110V |
|
AC Frequency |
47- 440Hz |
||
Cold Surge Current |
≤60A(AC220V input) |
≤30A(AC110V input) |
|
Leak Current |
≤0.7mA(AC220V input) |
0.4mA(AC110V input) |
|
Output |
Max Output Voltage |
DC 35KV |
|
Max Output Current |
DC 23mA |
||
Efficiency |
When> 90% load down |
||
Time no-failure |
>10000 hours |
||
Response Speed |
≤1ms(the time from output of switch signal to 90%of initial setting current) |
||
Control port |
TTL electricity level switch control, valid electricity has high/low level choices |
||
Voltage-resisting |
Input-Output ,input-machine hull: 1500V 10mA 60s AC output cathode and machine hull connection |
||
Protection |
Can be used an opening way in a short timerequest the outer shell be good to connect the ground avoid arcing between anode and machine hull connection in the machine |
||
Usage Environment |
Work temperature(-10 degrees centigrade to 40 degrees centigrade).Relative humidity≤90% |
||
Cooling Type |
The compulsive air cooling |
||
Size |
L×W×H=210×160×95mm |
||
