Industrial Switch Unmanaged Fast Ethernet Switch
- Shenzhen / FH-net
- T/T Money Gram Credit Card
You May Like
-
Network Switch Unmanaged Fast Ethernet 100Mbps
-
Industrial Ethernet Switch
-
5 Port 100M Passive PoE Switch 12/24/48V PoE Output Pin 45/78 CE FCC RoHS
-
POE Switch 5 Port 10/100Mbps Ethernet Switch Power Supply Switch
-
VLAN Support 5 PORT GIGABIT POE SWITCH With 5 Ethernet Port Power Over Ethernet Switch 4 POE Port and 1 Uplink
-
POE Ethernet Switch With 5 Port UL Power Supply SPE-2000GH
Product Details
| Place of Origin | Guangdong, China | Brand Name | FH-NET | |
| Model Number | FHC2003 |
Product Description
Product description
The FHC2003 has 2 ports 10M/100M and 1 port 100Base-FX optic port high performance auto-negotiation industrial Ethernet fiber optic converter, which is used to Ethernet signature communication.
Specification:
Port | |
Port type | 2 *10/100 Base-TX port + 1*100Base-FX |
Twisted-pair | RJ45 port, 10/100Base auto negotiation speed and auto MDI/MDI-X connection |
Fiber optic port | Multi-mode/Single-mode, ST/SC/FC port could be choose |
Communication distance | |
Twisted-pair | 0~100m |
Fiber optic line | 100Base-FX:multi-mode:<5km ; Single-mode:20km40km60km80km 1000BaseT:multi-mode:500M ; Single-mode:10km/40km/80km |
Power supply | |
Input Voltage | 24VDC:18-36V 48VDC(customer order) AC/DC:AC85-265V/DC110-370V |
Watt loss | <5W |
Environmental Limits | |
Operating | Standard Models: -35℃~75℃ |
Temperature | Storage Temperature: -40℃~85℃ |
Ambient Relative Humidity | 0~95%(non-condensing) |
Physical Characteristics | |
Dimension | 144mm×33mm×97mm |
Installation | DIN-Rail |
Weight | 0.5kg |
Case protection grade | IP40 |
Package | IEEE802.3u,IEEE802.3x,IEEE802.3 |
Ordering Information:
FHC2003-P | 2 *10/100 Base-TX port 1 *10M/100M adaptive port,1 Multi-mode 100Base-FX port,2km |
FHC2003-S-20 | 2 *10/100 Base-TX port 1 *10M/100M adaptive port,1 Single-mode 100Base-FX port,20km,DC24V |
FHC2003-S-40 | 2 *10/100 Base-TX port 1 *10M/100M adaptive port,1 Single-mode 100Base-FX port,40km,DC24V |
FHC2003-S-60 | 2 *10/100 Base-TX port 1 *10M/100M adaptive port,1 Single-mode 100Base-FX port,60km,DC24V |
FHC2003-S-80 | 2 *10/100 Base-TX port 1 *10M/100M adaptive port,1 Single-mode 100Base-FX port,80km,DC24V |
FHC2003-S-100 | 2 *10/100 Base-TX port 1 *10M/100M adaptive port,1 Single-mode 100Base-FX port,100km,DC24V |
