Ftth/FTTX 2*ge+wifi Gpon Ont Compatible With Huawei/ZTE/FIBERHOME/ZYXEL OLT

Introduction

GPON ONT/HGU is designed for FTTH and networking service providers.  FHR2201K is developed by FH-net optoeletronics based on the Gigabit GPON technology, has a high cost performance, it supports the 802.11n wireless networking technology(T/R). It is high stability and easy to maintain, has multi-service QoS quality guarantee. And It is fully compliant with technical regulations such as ITU-T G.984.x and technical requirement of GPON Equipment (V2.1 and above version) from China Telecom, China Unicom.

Characteristics

Main service: 1GE+1FE+1WIFI

Plug and play, integrate auto detection, auto configuration and auto firmware upgrading

Integrate OMCI and TR-069 remote configuration and maintenance

Support flexible QinQ VLAN,DHCP server/relay and IGMP/ MLD multicast monitoring function

Support diagnostic monitoring and remote disabling of fiber optical

Compatible with Huawei,ZTE and Fiberhome OLT

Support 802.11n WiFi(T/R)function

Support NAT and firewall function

WAN support networking bridge, router and bridge/router mixed mode

  Specification

Data Service Functions

Full speed 1G non-blocking switching

2048 MAC address table

Support VLAN QinQ, transparent, tag, translation, trunk, etc.

Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc

Support auto polarity detection of Ethernet ports (AUTO MDIX)

Integrated IEEE802.1p QoS with four level priority queues

Support IPv4 IGMP snooping and IPv6 MLD snooping

Support bridging, router and bridging/router mixed mode

Wi-Fi service

Support Integrated 802.11b/g/n, 300Mbps, 2T2R.

Support 64 connections

Support WEP and WPA/WPA2 security protocols.
