advertising led display screen xxx video outdoor P6
specification:
| Item | P6 |
| Pixel pitch | 6 (mm) |
| Pixel configuration | 1R1G1B 3in1 |
| Pixel density | 27777 pixels/sq.m. |
| Brightness | ≥5000cd/m² |
| Weight | 25-30kg/sqm |
| Module pixel | 32*16 dot |
| Module dimensions (W×H) | 192*96 (mm) |
| Module dimensions (W×H) | 7.7*3.8 (Inch) |
| Cabinet Resolution | 96*96 dot |
| Cabinet dimension | 576*576*78mm |
| Refresh rate | ≥2000 Hz |
| Gray scale | 65536 |
| Colors | 281 trillion |
| Viewing angle (H/V) | 120/80 (deg) |
| IP rating (Front/Rear) | IP65/IP54 |
| Power consumption (max/avg) | 600/300 (W/sq.m.) |
| Drive mode | 1/4 constant current static |
| Input voltage (AC) | 100V ~ 240V |
| Operating temperature | -20°C ~+ 40°C |
| Operating humidity | 10% ~ 85% |
| Source compatibility (with video processor) | VGA, DVI, HDMI, SDI |
| Control distance | Network Cable≤100m, Multimode optical fiber≤500m, Single mode optical fiber≤20 kilometer |
Features:
1,P6 outdoor led display screen cabinet weight is only 8.15 kg, depth 75 mm, decreasing the transportation cost and the intensity of labor.
2,P6mm outdoor led display screen with quiet fan design, excellent heat dissipation, noiseless. Quick locks connecting cabinets, only 10 seconds per cabinet.
3,High polymer flexible mask, no dazzle, better contrast ratio; the masks can be pulled off directly from the cabinet, which makes the maintenance much more convenient.
4,High-performance aluminum cabinet, which could bear the weight of 20 cabinets in a vertical line. Louver window design, dust proof & excellent heat dissipation.
5,With intelligent control LCD monitor, easy to know the correct accumulated working time. Pop out back door, much more convenient for the examination and maintenance.
