Product Details
Place of Origin: | Jiangsu, China | Brand Name: | RELIANCE | Model Number: | RS-12 240 |
Specification: | Mini | Application: | Commercial | Output Voltage (V): | 12 |
Load Power (W): | 100w | Solar Power (W): | 400w | Work Time (h): | 30rh |
Product Description
Specifications
Solar power systemSolar power system is a kind of energy-saving and environmental protection product. The working principle i
Solar power system
Solar power system is a kind of energy-saving and environmental protection product. The working principle is: Solar panels absorb sunshine and transfer into electricity, then store in and built -in battery, Power load,such as lamp ,TV,DVD Fan ,etc.
Main Feature
1.Solar panel :Using Mono/Poly silicon solar cell ,encapsulated with toughtened glass,Lifespan can up to 25 years
2.Rechargeable battery :matintenance -free ,led -acid batttery
3.Control system:Design for solar system,has over-charger & over -discharged protection function
4.Controller:protect battery and load
5.Statement:data only for reference
Advantage:
*Proferssional design for home
*High efficiency & reliability
*When the equipment shorting out ,overload and overdischarge or overcharge ,the system will automatically protec the function
*Excellent compatibility
*Excellent Adaptability
*Engineered to high standards
*Guaranteed durability
*The solar power system structure is simple and its application effect is mutifunctional ,Suitable for home use
Model | RS12-400 | ||
Rated Charging Current | 5A | ||
Rated Discharge Current | 12.5A | ||
Rated Working Voltage | 12V | ||
Float Charge Voltage | 14V | ||
Low-voltage Protection | 10.7V | ||
USB Port | 5V 500mA | ||
Working Temperature | -10°C~50°C | ||
Solar Panel Voltage | ≤25V | ||
Panel Power | 40W | ||
BAT. Low Recovery | 11.5V | ||
No-load Loss | ≤8mA | ||
Controller | 12v5 | ||
battery | Lead acid battery 12v40ah | ||
Output Voltage | 3*12v outports+2 USB outports | ||
Charging time | 2days | ||
Using time 2*3W bulb+10w fan+tv 30w | 8hrs | ||
Panel sizes panel:650*506*30 | Generator sizes:260*230*210 14kg | ||
20ft container loading | 1100sets | ||
Accessories | QTY | ||
1 | 18V/40W Solar panel(4m cable with DC plug) | 1pc | |
2 | 12V/3W LED LAMP(4m cable with DC plug) | 2pcs | |
3 | 10 heads mobile charger | 1pc | |
4 | DC wire | 1pc | |
5 | 12v 5A electricity digital charger | optional | |
6 | 3W USB Fan | Optional | |
7 | 10W DC Fan | Optional | |
F | MINIMUM 30PCS |
