Slaughterhouse waste Rendering plant(Feather, bone, offals)

Name: Slaughterhouse waste Rendering plant(Feather, bone, offals)
Brand: Wanxin
Price: USD $115,000 - 546,000 / Set

FOB Price

USD $115,000 - $546,000 / Set

1 Set(Min.Order)

Supply Ability 10 Set / Sets per Month
Port Qingdao Shnaghai
Payment Terms:T/T Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Application:	Poultry	Place of Origin:	Shandong, China
Brand Name:	Wanxin	Model Number:	N/M	Voltage:	as need
Power(W):	125kw	Dimension(LWH):	35124.5meter	Weight:	15000kg
Certification:	ISO9001:2000	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

Definitions

Rendering provides a means of efficient disposal of animal by-products and conservation of other resources. If rendering were not used to dispose of these by-products they would most likely be sent to a landfill or incinerated.

Raw Material:

The dead animals and slaughterhouses waste which rendering plants recycle includes:

<![if !supportLists]>1. <![endif]>Slaughterhouses waste such as heads and hooves from cattle, sheep, pigs and horses, blood, stomachs, intestines, spinal cords, tails, feathers, an bones.

<![if !supportLists]>2. <![endif]>Thousands of euthanized cats and dogs from veterinarians and animal shelters

<![if !supportLists]>3. <![endif]>Dead animals such as skunks, rats, and raccoons

<![if !supportLists]>4. <![endif]>Carcasses of pets, livestock, poultry waste

<![if !supportLists]>5. <![endif]>Supermarket rejects

<![if !supportLists]>6. <![endif]>

The Process

Animal by-products are collected from butcher shops, restaurants, supermarkets, farmers, abattoirs and other operations to be processed under high temperatures in order to remove water and to eliminate bacteria.

Modern rendering plants use automated continuous systems which breaks down the material to its base elements; protein, minerals, water and fat.

The resulting finished products are then either returned to the agricultural chain in the form of feed supplements or used in industrial and consumer products.

Rendered Products

The plant produces the following quality by-products:

Poultry Meal

Meat and Bone Meal (mixed species)

Feather Meal

Blood Meal

Tallow (mixed species)

Poultry Tallow

Poultry meal

Feather meal is made from poultry by feathers and is used as a feed substitute for fishmeal in aquaculture feed. The feathers are hydrolysed under elevated heat and pressure and then processed.

Feather Meal is unique because of its naturally high protein content and the controlled hydrolisation process ensures optimised disgestibility of the protein.

Feathermeal Specification
Protein	80% Min
Moisture	10% Max
Fat	4% Max
Pepsin Digestibility	75% Min

Meat & Bone Meal (mixed)

Meat and Bonemeal Specification
Protein	50% Min
Moisture	8% Max
Fat	14% Max
Ash	35% Max
Fibre	3% Max
Wool and Hair	1% Max
Pepsin Digestibility	85% Min

Blood Meal

Blood meal is produced by steam - heated disc drying following steam coagulation and decanting

Blood meal Specification
Protein	85% Min
Moisture	10% Max
Fat	1.5% Max
Ash	6% Max

Equipment list for Red meat(pig,cattle, sheep ect.) rendering plant

Capacity: 1-10 MT per shift ( 2 shifts per day)

Work time: 3-5hours per shift

Working status: continuous and batch type

Work temperature: 135~140 degree

Work pressure: 0.4~0.6Mpa

Raw material handling section

One (1) crusher,

One (1) crusher discharge conveyor

One (1) batch cooker loading conveyor

Cooking and drying section :

One (1) batch cooker, loading volume : 10.000 L

One (1) shut off valve (pneumatic)

One (1) set of valves for vapors, steam, condensate and safety.

Defatting and meal handling section

One (1) cyclone, all stainless steel

One (1) reception bin

One (1) press feeding conveyor

One (1) screw press

One (1) balance tank with one (1) tallow pump

One (1) press discharge conveyor

One (1) greaves curing bin

One (1) hammer mill feeding conveyor

One (1) hammer mill, Sprout-Matador

One (1) hammer mill platform

One (1) discharge conveyor+ bagging system

Fat handling section

One (1) fat collection tank

One (1) decanter feeding pump

One (1) decanter, brand : Alfa-Laval, model : NX314

One (1) decanter platform

One (1) balance tank with one (1) tallow pump

Vapour handling section

One (1) cyclone, all stainless steel

One (1) S&T (Shell & Tube) condenser

One (1) condensate tank, SS

One (1) water cooling unit

One (1) set of piping, SS

Mixed poultry rendering plant

Capacity: 1-10MT per shift

Equipment List:

Equipped with :
-Steam and condensate accessories(double safety valves, shut off valves, sight glass and steam traps,…)
-Pneumatic shut off sliding valves (DN600) for loading gates
-Loading cells
-Electric operated discharge doors
-Three (3) cyclones, SS with piping
-Meal discharge bins(two conveyors on bottom)
-Conveyor to vibrating screen
-Vibrating screen
-Conveyors to discharge the meal on the floor
-Electric panel
-Shell and tube condensors with their piping, SS
-Water coolers with their piping, SS
-Air washer with fan with their piping, SS
-Steam boiler, Wanson with accessories and chimney, SS

Please feel free to ask us for more details....
