Product Details
Condition: | New | Application: | Poultry | Place of Origin: | Shandong, China |
Brand Name: | WANXIN | Model Number: | Wx-4 | Voltage: | Customized |
Power(W): | 7.5KW | Dimension(L*W*H): | 4200*1600*1200mm | Weight: | 1500kg |
Certification: | ISO9001:2000 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Manufacture of Crate Washer/Washing Machine for Food, Poultry
Quick Detail:
- Capacity Supply: According to customer's requirement
- Engineer make turn-key solution for your product drink
- Warranty: 1 year and free spare parts in one year
- Engineers available to service machinery overseas
- Place of Origin: Zhangjiagang city, China near Shanghai
- Brand: BJM
- Delivery Time: 30 days
- Shipping: Sea
Introduction
The wash and sterilize the crate using in food, poultry, kitchen etc. The machine can be designed by customer’s crate and requirement.
Description:
1, The equipment uses stainless steel SUS304 excluding electrical machine and jet nozzle which is made of plastic of resisting temperature and convenient to dismounting.
2, 4 groups of spray has a separate loop filtering tank except fresh water which is recycled to the hot water tank as supplement water, then heat and eject part of the direct water. The disinfectant fluid in sterilizer tank is mixed and replenished by labour. There are steam heating tube is equipped in hot alkaline tank and hot water tank, the temperature can be freely adjusted and controlled from room temperature to 100℃.
3, Motor power of conveyor is 0,55kw, transmit speed is 3-15m/min and can be adjusted.
4, Two sides of washed machine are waterproof activities door, waterproof soft curtain on both ends, convenient to clean, examine and repair at all times.
5, Pneumatic adjustment device can be equipped, which can automatic adjust guardrail spacing, can wash the crate of different specifications.
6, The machine is provided with stainless steel electrical control cabinet, centralized control the whole power.
7, Completely cleaning and sterilizing in one time
Parameter:
Item | Parameter |
Capacity | 50-1000 crates per hour |
Power | 4kw |
Voltage | 380V/50HZ(custom made) |
Conveyor speed | 3-15m/min adjustment |
Competitive Advantage:
Main parts Supplier:
Main parts Name | Supplier |
Main motor | Siemens |
Spray Pump | South pump |
Touch screen | Taiwan company |
PLC | Mitsubishi Japan |
Transducer | Mitsubishi Japan |
Proximity & photoelectric switch | Omron |
Contactor, circuit breaker | Snyder French |
Cylinder and magnetic valve | Airtac Taiwan |
- Experienced in this field more than 20 years
- Free technical support&consultation
- Professional & fast after service team
- Warranty: 12 months
- Free spare parts for one year
- Delivery time: in time
- Engineers available to service machinery overseas
Benjamin Machinery pays great attention to technology, such as beer processing and filling technology, high-viscosity filling technology, glass bottle water filling technology.
And we will try our best to satisfy your requirement; your message will be highly appreciated. Welcome to Benjamin Machinery.
