High Brightness Semi-outdoor Variable Message Signs P10

Name: High Brightness Semi-outdoor Variable Message Signs P10
Brand: Jing Cai
SKU: 110541089

US$ 400 - 600 MOQ: 1 Piece

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

Jing Cai

Model Number:

p10

Fujian Brilliantopto Co., Limited

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name Jing Cai

Model Number p10

Usage Semi-outdoor

Tube Chip Color Other, 1R1B.1R1G

Display Function Video

Specifications

semi-outdoor variable message signs p10
1.CE,RoHS,FCC
2.low consumption
3.quality insuranced by CPIC

Brilliant Optoelectronic Technology Co., Ltd

Established in 2005, ,we are a professional manufacturer of LED display system and lighting products,

with the registered capital 20.18 million,own workshop area 20000 m² ,branch office and agents cover all over china.

Semi outdoor variable message signs p10

Module details

1.Certification:CE/ROHS/FCC/UL/ISO

2.Promotion price

3.high specification encapsulation

4.quality insuranced by CPIC

5.3 years QA

Technical Parameters of P10Semi- Outdoor Full Clor Display
Item	Speciation
Physical Pitch	10mm
Pixel Configuration	1R1G 1R1B
LED Specification	346
Cell Board Dimension	320*160
Unit Board Dimension(Length*Width)	32*16
Dot ensity (Dot/m²⁾	10000
Brightness(cd/m²⁾	≥6000
The Best Visual Distance	38m
Scanning Mode	Static constant-current
Peak Power Consumption	1600
Visual Angle	Horizon 110Degree, Vertical 90Degree
Grey Scale	Red,Green,Blue,Each 4096 Levels
Display Colors	4096 ^∧3Pixels
Brightness Adjustment	Manual opration,Red,Blue 256Levels,Automatically8 Level Adjustment.
Control Method	in SYNCHRONISM(off-control System,S-UTP Neting Twine OR optical Fiber Transimission)
Lamp Beads Life	One Hundred Thousand Hours
Operating Pressure	AC110v/AC220V±15%50HZ/60HZ
Control Distance	less Than 140 Meter(No Replaying),Multimodes 500Meters/Single Mode.
Systematic Operating Ambient Temperature	–30°C to50°C
Systematic Operating Ambient Humidity	10% to 90%RH
Cabinet Material	Frame/Cabinet
