Clear RGB Full Color Led Display Outdoor 10mm

Name: Clear RGB Full Color Led Display Outdoor 10mm
Brand: Jingcai
SKU: 110540589
Availability: InStock

Negotiable MOQ: 12 Square Meters (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

Jingcai

Model Number:

P10

Fujian Brilliantopto Co., Limited

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

xiamen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name Jingcai

Model Number P10

Usage Outdoor

Tube Chip Color Full Color

Display Function Video

Pixels 10mm

Specifications

Clear RGB full color led display outdoor 10mm
1.Certification: CE/ROHS/CCC/UL
2.Hot sale
3.Promotion Price

Clear RGB full color led display outdoor 10mm

The parameters of Clear RGB full color led display outdoor 10mm
Pixel pitch	10mm
Module size	320mm×160mm
Module density	10,000dots/sqm
Module resolution	32×16
Pixel configuration	1R1G1B
Red wavelength	625±2nm
Green wavelength	525±2nm
Blue wavelength	470±2nm
Colors	16777216
Best viewing distance	More than 10 m
Horizontal viewing angle	120°
Vertical viewing angle	60°
Maximum power consumption	Below 1100W
Brightness	10000cd/sqm
Gray scale	14 bits of per color
Control method	Synchronization
Driving method	1/4 scanning
Frame frequency	60Hz
Refresh frequency	More than 300 Hz
Working voltage	AC220V/110V±10%
IP grade	IP65
Working temperature	-20°C±70°C
MTBF	More than 10,000 hours
Life span	More than 100,000hours
