Specifications
1.Perfect color mixing effects2.High refresh rate and clear image quality
3.Wide viewing angle
4.Perfect light distribution
Pixel pitch | 25mm |
Module size | 400mm×200mm |
Module density | 1600dots/sqm |
Module resolution | 16×8 |
Pixel configuration | 2R1G1B |
Red wavelength | 625±2nm |
Green wavelength | 525±2nm |
Blue wavelength | 470±2nm |
Colors | 16777216 |
Best viewing distance | From 25 to 200 |
Horizontal viewing angle | 120° |
Vertical viewing angle | 60° |
Maximum power consumption | Below 550W |
Brightness | 5500cd/sqm |
Gray scale | More than 4096 |
Color temperature | 6500K |
Control method | Synchronization |
Driving method | static constent current |
Frame frequency | 60Hz |
Refresh frequency | More than 300 Hz |
Working voltage | AC220V/110V±10% |
IP grade | IP65 |
Working temperature | -20°C±70°C |
MTBF | More than 10,000 hours |
Life span | More than 100,000hours |
