Home > Consumer Electronics > LED Display > Indoor LED Display > Waterproof Outdoor tv Cabinet Led Display Board

Waterproof Outdoor tv Cabinet Led Display Board

Waterproof Outdoor tv Cabinet Led Display Board photo-1
US$ 60 - 100 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
jiangcai
Model Number:
p10
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Fujian, China
Brand Name jiangcai
Model Number p10
Usage Indoor
Tube Chip Color Full Color
Display Function Video
Pixels 10mm

Specifications

P10 waterproof outdoor cabinet
1.1R1G1B
2.24 hours services
3.CE/ROHS/UL/CCC/FCC/ISO9001

aliexpress P10 waterproof outdoor tv cabinet Brilliant Opto Technology Co.,Ltd [JingCai (Fujian) Optoelectronics Co., LTD] is professional development manufacturing LED display system products and lighting products, was founded in 2005, with the registered capital 20.18 million, own workshop area 20000 m2, branch office and agents cover all over China, with about 400 employees. We have 21 engineers and 5 of them are senior.

   waterproof outdoor tv cabinet led display board

The technical parameters of P10 outdoor full color led display

Pixel pitch

10mm

Module size

160×160mm

Module density

10,000dots/sqm

Module resolution

16×16

Pixel configuration

1R1G1B

Red wavelength

OPTO taiwan 625±2nm

Green wavelength

Silan taiwan 525±2nm

Blue wavelength

Silan taiwan 470±2nm

Best viewing distance

From 10 to 150

Horizontal viewing angle

110°

Vertical viewing angle

60°

Maximum power consumption

Below 1100W

Brightness

7000cd/sqm

Gray scale

More than 4096

Control method

Synchronization

Driving method

4Sconstant current

Frame frequency

60Hz

Refresh frequency

More than 300 Hz

Working voltage

AC220V±5%

IP grade

IP65

Working temperature

-20°C±50°C

MTBF

More than 10,000 hours

Life span

More than 100,000hours

Cabinet style

Waterproof cabinet

Cabinet size

W640*H640*D120mm
