fiber cable protection tube
- 10000 Piece / Pieces per Month
- Tianjin Port
- T/T L/C D/P D/A Credit Card
- Semiconductor quartz boats to protect chips from chemical solution, resistant to strong acids and alkalis
- custom Quartz Ground Joints Standard ball bowl Quartz Joint Connector With Good Thermal Stability
- OEM Quartz Box
- Customized Semicircular quartz boat Chemical loader fused quartz glass boat
- SiO2 Target
- Be all things to all men crystal for heat press
Product Details
Place of Origin: | Beijing, China | Brand Name: | ZCQ | Model Number: | Various |
Application: | Fiber Optic Materials Electronics, Medical Treatment, Bioengineering | Shape: | Various | Dimensions: | Various |
Chemical Composition: | SiO2 |
Product Description
fiber cable protection tube
Dimension: Round-shape or Quadrate capillary tube
OD: from 0.127mm to 11mm
Length: Customer Design
Products features:
Clear and clean,
High homogeneity
High temperature resistant
High light transmission
Anti chemistry attack
Working temperature:
Regular working temperature: 1000°C
Working temperature for short term:1100°C
instant working max temperature:1300°C
Mechanical Property:
Mechanical Property | Reference Value | Mechanical Property | Reference Value |
Density | 2.203g/cm3 | Refractive Index | 1.45845 |
Compressive Strength | >1100Mpa | Coefficient of thermal expansion | 5.5×10-7cm/cm.°C |
Bending Strength | 67Mpa | Hot work temperature | 1750~2050°C |
Tensile Strength | 48.3Mpa | The temperature for a short time | 1300°C |
Poisson's Ratio | 0.14~0.17 | The temperature for a long time | 1100°C |
Elastic Modulus | 71700Mpa | Resistivity | 7×107Ω.cm |
Shearing Modulus | 31000Mpa | Dielectric Strength | 250~400Kv/cm |
Moths Hardness | 5.3~6.5(Moths Scale) | Dielectric Constant | 3.7~3.9 |
Deformation Point | 1280°C | Dielectric absorption coefficient | <4×104 |
Specific Heat(20~350°C) | 670J/kg °C | Dielectric loss coefficient | <1×104 |
Thermal Conductivity(20°C) | 1.4W/m °C |
|
Use Notices
1. Do not operate in temperature beyond quartz maximum working temperature for long time.
Otherwise, products will deform crystallization or become softening.
2. Clean the quartz products before high temperature environment operation .
Firstly soak the products in 10% hydrofluoric acid, then wash it with high purity water or alcohol .
Operator should wear thin gloves , direct touch with the quartz glass by hand is inhibited.
3. It is wise to extend the lifespan and thermal resistance of quartz products via continuous use
within high temperature environment. Otherwise, interval use shall shorten products lifespan.
4. Try to avoid touch with alkaline substances (such as water glass, asbestos, potassium and sodium compounds, etc.)
when employing quartz glass products in high temperature, which is made of acid material.
Otherwise product anti- crystalline properties will be greatly reduced.
