wholesale price borosilicate glass tube pipes 6*0.77*6mm
- 1000 Piece / Pieces per Month
- Tianjin Port
- T/T L/C D/P D/A
- Borosilicate Glass Plate Water Level Gauge Toughened Glass Plate Water Level Gauge with Glass Plate Liquid Level Gauge
- Factory Price transparent Reflex Water boiler DIN 7081 Standard A0-A9/B0-B9 KLINGER glass level gauge without slot
- China Borosilicate Reflex DIN 7081 Standard High pressure Boiler level gauge glass in boiler
- high borosilicate clear Optical Use Tempered temperature resistance Round Shape circular sight glass disc borosilicate
- High quality Water boiler Boiler Part KLINGER DIN 7081 Standard A0-A9/B0-B9 Water boiler Gauge Level Glass
- factory heat-resistant high borosilicate clear Tempered Pyrex borosilicate 3.3 circular Circular sight glass
Product Details
Place of Origin: | Beijing, China | Brand Name: | ZCQ | Model Number: | ZCQ |
Size: | OEM | Type: | Curved Glass | Application: | Automotive Glass |
Thickness: | 1mm to 20mm | Composition: | Optical Glass |
Product Description
Product Introductions borosilicate glass tube pipes
Material | Basic Dimension |
Borosilicate Tube | OD:6.0mm (+/-0.1mm) ID:1.45mm (+/-0.01mm) Length:6mm (+/-1mm) |
Borosilicate Tube | OD:6.0mm ID:0.90mm Length:6mm
|
Borosilicate Tube | OD:6.0mm (+/-0.1mm) ID:1.45mm (+/-0.01mm) Length:6mm (+/-1mm) |
Borosilicate Tube | OD:6.0mm ID:0.77mm Length:6mm |
Borosilicate Tube | OD:6.0mm (+/-0.1mm) ID:1.8mm (+/-0.01mm) Length:100mm (+/-1mm)
|
OD SIZE:6mm ID size : 0.62mm 0.77mm 0.80mm |
0.90mm 0.95mm 1.00mm 1.08mm 1.20mm |
1.30mm 1.45mm 1.52mm 1.70mm 1.91mm |
Other dimensions and tolerance is based on customers requirements.
About borosilicate borosilicate glass tube pipes
Borosilicate glass has a very good homogeneity and very high transparency in the UV/visible/near IR range. The glass has low thermal expansion and high thermal resistance that make it particularly suitable for areas of application where high temperatures and thermal gradients are involved.
Thermal Properties borosilicate glass tube pipes
Borosilicate glass has one of the lowest coefficients of thermal expansion for conventional glass materials, this provides with good thermal shock resistance. Combined with a maximum long term use temperature of 450°C, which makes borosilicate glass a good choice for applications requiring good thermal stability.
Coefficient of Thermal Expansion | (α 20 - 300° C ) | 3.25 x 10-6/K |
Thermal Conductivity(λ) | 10°C 50°C 90°C 190° C | 1.11 W/m K 1.17 W/m K 1.22 W/m K 1.31 W/m K |
Heat Capacity(Cp) | 20 - 100°C | 0.83 kJ/kg K |
Maximum Operating Temperature | Short-term Long-term | 500°C 450°C |
Resistance to Thermal Gradients | < 1 hour 1 - 100 hours > 100 hours | 110K 90K 80K |
Resistance to Thermal Shock | < 4 mm 4-6 mm 6-15 mm > 15 mm | 175K 160K 150K 140K |
ZCQ is a full value-added distributor in custom quartz products manufacturing. We believe customers should be regarded as root of the trees if a company desires flourishment and fruits. Our mission is to provide a comprehensive suite of services related to meet your needs. We go out of our way to ensure that you receive the service and personal attention you deserve.
ISO 9001and ROHS Certified –We are ISO 9001 and RoHS Certified, and will provide any certifications you need about the quality of our products. Our company founding and manufacturing history can be dated back to 1998.
Quotes in 24 Hours or Less– Each Enquiry is replied within 24 hours. Individual sales representative is also pleased to answer your phone call within or out of office time. Please send email us in case international phone call cant be reached.
Low Order Minimum – Just $35 for you to order any group of quartz products in or out of stock.
Custom and prototyping are welcome–We welcome custom quartz products to meet your exact specifications. With a team of senior quartz experts, we can also offer advises on product design for free.
Prompt Lead TimesFor products in stock, product will be delivered in 1 or 2 days.For custom products, it takes 5-10 days. No matter what type, we try to understand and support customer’s time requirement.
On-Time Delivery In 5-7 or 10-20 days, Product parcel shall arrive at assigned destinations.
Shipping methods via China post(15-20 days) Epacket (10-15days) EMS(7-10days) Fedex(5-7days) DHL(5-7days)
Free Samples We are pleased to send free samples to customers whoever interested in business and cooperation with us. Shipping charge shall be paid by customers from the other part of the globe.
Company tour invitation 1 hour from international meeting center of Beijing, ZCQ invites guests to visit our company after long day meeting and get relaxed in nature. Our company is also sitted in arms of mountains and river.
With over 70 personnel in sales and support alone, ZCQ is ready to handle even the most difficult request. We hope you will have the most content quartz products buying experience possible and can focus on your core strengths.
Questions and help
If you have any questions concerning products, please call us at 86-10-89770383 ,86-13241781622 or email us .
Order Acceptance and Pricing
ZCQ will provide a Pro Forma Invoice as confirmation on customers’ order.
Production will be arranged in line with technical specification within the invoice once payment received .
Payment Terms
Advanced T/T Credit Card Payments: ZCQ accepts Visa, MasterCard, and American Express.
We also accepts paypal payment .
Shipping & Handling
Freight Policy: If you have a freight collect account with any shipping carrier, please tell us in advance.
Or we will advise you a most economic method of shipment before checkout.
Return/Guarantee Policy
A Return Merchandise is to be returned on the original shipping form. Returns may be subject to freight. Credit will not be issued until the return has been received and inspected by ZCQ. Please send us an email and include your order number.
