Product Introductions Borosilicate 3.3 Glass Tube
Material |
Basic Dimension |
|
Borosilicate Tube |
OD:6.0mm (+/-0.1mm) ID:1.45mm (+/-0.01mm) Length:6mm (+/-1mm) |
| Borosilicate Tube |
OD:6.0mm ID:0.90mm Length:6mm
|
|
Borosilicate Tube |
OD:6.0mm (+/-0.1mm) ID:1.45mm (+/-0.01mm) Length:6mm (+/-1mm) |
| Borosilicate Tube |
OD:6.0mm ID:0.77mm Length:6mm |
|
Borosilicate Tube |
OD:6.0mm (+/-0.1mm) ID:1.8mm (+/-0.01mm) Length:100mm (+/-1mm)
|
|
OD SIZE:6mm ID size : 0.62mm 0.77mm 0.80mm |
|
0.90mm 0.95mm 1.00mm 1.08mm 1.20mm |
|
1.30mm 1.45mm 1.52mm 1.70mm 1.91mm |
Other dimensions and tolerance is based on customers requirements.
About borosilicate Borosilicate 3.3 Glass Tube
Borosilicate glass has a very good homogeneity and very high transparency in the UV/visible/near IR range. The glass has low thermal expansion and high thermal resistance that make it particularly suitable for areas of application where high temperatures and thermal gradients are involved.
Thermal Properties Borosilicate 3.3 Glass Tube
Borosilicate glass has one of the lowest coefficients of thermal expansion for conventional glass materials, this provides with good thermal shock resistance. Combined with a maximum long term use temperature of 450°C, which makes borosilicate glass a good choice for applications requiring good thermal stability.
| Coefficient of Thermal Expansion | (α 20 - 300° C ) | 3.25 x 10-6/K |
| Thermal Conductivity(λ) | 10°C 50°C 90°C 190° C |
1.11 W/m K 1.17 W/m K 1.22 W/m K 1.31 W/m K |
| Heat Capacity(Cp) | 20 - 100°C | 0.83 kJ/kg K |
| Maximum Operating Temperature | Short-term Long-term |
500°C 450°C |
| Resistance to Thermal Gradients | < 1 hour 1 - 100 hours > 100 hours |
110K 90K 80K |
| Resistance to Thermal Shock | < 4 mm 4-6 mm 6-15 mm > 15 mm |
175K 160K 150K 140K |
