High Efficiency Small Wind Generator Wind Turbine

Name: High Efficiency Small Wind Generator Wind Turbine
Brand: Newsky
SKU: 110475253
Availability: InStock

US$ 200 - 400 MOQ: 1 Piece

Key Specifications

Place of Origin:

China

Brand Name:

Newsky

Model Number:

Min400W

Qingdao Commercial Energy Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name Newsky

Model Number Min400W

Type Wind Power Generator

Specifications

High efficiency small wind generator wind turbine
1,Bearing from "SKF"
2,Easy installation,
3,Free of maintentanence

High efficiency small wind generator wind turbine

Features High efficiency small wind generator wind turbine

1.Bearing from “SKF” Sweden.

2.Stainless steel screw bolt from “THE”.

3.Primary aluminum housing, not secondary aluminum.

4. Low start-up wind speed.

5.High-efficient Generator

6.Innovative Noise Reduction Technology

7.Perfect Wind Wheel System

8.Unique Design Of The Rudder

9. Damp-proof, sand-proof, Anti-rust, Anticorrosion

10 .Easy installation, Free of maintenance, Long lifespan over 15years.

Specifications High efficiency small wind generator wind turbine

Model	Mini400W-3	Mini400W-5
Rated power	400 watts at 12 m/s
Max Capacity	450watts
Voltage	12, 24 VDC
Blades	3 Pcs Nylon Fiber	5 Pcs Nylon Fiber
Start-Up Wind Speed	2.0 ( m/s)	1.5 ( m/s)
Cut-In Wind Speed	2.5(m/s)	2.0(m.s)
Rotor Diameter	1.16 m	1.21m
Weight	6.2 kg	7.1 kg
Shipping Dimensions	770x 410x 200 mm (8.3 kg)	770x 410x 200 mm ( 9 kg)
KWH per Month	30KWh at 3.2 m/s	42KWh at 3.2 m/s
Mount	1.9 inch (48 mm) OD pipe
Turbine Controller	Microprocessor-based smart internal regulator with Maximum Power Point Tracking
Body	Cast aluminum
Overspeed Protection	Electronic torque control
Working temperature	—40°C~ 150°C
Certificate	ISO9001:2008 ,CE, Rohs
Survival Wind Speed	50 m/s
Warranty	3 year limited warranty
