Home > Products > MMA/ARC Welder > MMA-105 DC Welding Machine
MMA-105 DC Welding Machine
- NINGBO or SHANGHAI
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | KENMAI | Model Number | MMA-105 | |
| Arc Current | 5-105 | Pulse Frequency | 50/60 | |
| Pilot Arc Current | 5-105 | Rated Duty Cycle | 25% | |
| Dimensions | 350*220*260(mm) | Usage | welding machine | |
| Voltage | 230v | Certification | CE, ROHS | |
| Warranty | one year |
Product Description
Specifications
MMA-105 DC Welding Machine1.Sound-proof.
2.DC hand electrode
3.Use MOS/IGBT technnology
4.Less splash, good weld appearance
MMA-105 DC Welding Machine
Technical Specification
| model specification | MMA-105 |
| Rated Input Voltage(V) | 230 |
| Input Capacity(KVA) | 3.0 |
| Frequency(Hz) | 50/60 |
| No-load Voltage(V) | 56 |
| Current Range(A) | 5-105 |
| Output Voltage(V) | 24.2 |
| Rated Duty Cycle(%) | 25 |
| Efficiency(%) | 85 |
| Applied Welding Rod(mm) | 0.8-2.5 |
| Class of Insulation | B |
| Case Protection Degree | IP21 |
| Net Weight(kg) | 5.0 |
| Dimension(mm) | 350*220*260 |
Main Features of MMA-105
1.Adopt with advanced MOS/IGBT inverter technology, save energy, protect the environment, light and compact, portable, accord with EMC standard.
2.Current can be adjusted stepless, high efficiency.
3.Fan-cooled, automatic protection of over-voltage and over-current, thermostatic protection, moveable welding cable.
4.Strong welding permeability, less splash, good weld appearance, sound-proof.
5.Suit for all kinds of basic and acid electrodes.
6.Be able to long-distance weld all kinds of material, such as stainless steel, steel, tungsten, titanium, nickel and other alloy material.
7.With complete accessories.
8.Carton box/BMC.
