Portable Hand Electrode Welder

Portable Hand Electrode Welder photo-1
US$ 63 - 65 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
KENMAI
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO or SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Zhejiang, China
Brand Name KENMAI
Model Number MMA-105
Arc Current 5-105
Pulse Frequency 50/60
Pilot Arc Current 5-105
Rated Duty Cycle 25%
Dimensions 350*220*260(mm)
Usage MMA DC hand electrode welding machine
Voltage 230v
Certification CE, ROHS
Warranty one year

Specifications

MMA DC Hand electrode Welder
1.Sound-proof
2.Use MOS/IGBT technology
3.less splash, good weld appearance

MMA-105 MMA DC Hand electrode Welder


Technical Specification

               Model   Specification                         MMA-105
Rated input voltage(V) 230
Input capacity(KW) 3.2
Frequency(Hz) 50/60
No-load voltage(V) 56
Current range(A) 5-105
Output voltage(V) 24.2
Rated duty cycle(%) 25
Efficiency(%) 85
Applied welding rod(mm) 0.8-2.5
Class of insulation B
Case protection degree IP21
Weight(KG) 9
Dimension(mm) 350*220*260



Main Features of MMA-105 welding machine

1.Adopt with advanced MOS/IGBT inverter technology, save energy, protect the environment, light and compact, portable, accord with EMC standard.

2.Current can be adjusted stepless, high efficiency.

3.Fan-cooled, automatic protection of over-voltage and over-current, thermostatic protection, moveable welding cable.

4.Strong welding permeability, less splash, good weld appearance, sound-proof.

5.Suit for all kinds of basic and acid electrodes.

6.Be able to long-distance weld all kinds of material, such as stainless steel, steel, tungsten, titanium, nickel and other alloy material.

7.With complete accessories.

8.Carton box/BMC.
