free energy generator wind generator wind turbine for home use

Name: free energy generator wind generator wind turbine for home use
Brand: NEWSKY
Availability: InStock

FOB Price

USD $214 - $392 / Piece

1 Piece(Min.Order)

Supply Ability 5000 Piece / Pieces per Month
Port NINGBO
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	NEWSKY
Model Number	MINI400-5PLUS		Type	Wind Power Generator

Product Description

Specifications

free energy generator wind generator wind turbine for home use
CE,ROHS
Bearing: Sweden SKF

Product Description

Free energy wind generator wind turbine

Models

400W, 600W, 800W, 1200W, 1600W

Features

Bearing: Sweden SKF

Stainless steel screw bolt: Brand THE

100% Primary aluminum housing, not secondary aluminum

Low start-up wind speed

High-efficient Generator

Perfect Wind Wheel System

Unique Design Of The Rudder

Damp-proof, sand-proof, Anti-rust, Anticorrosion

Easy installation, Free of maintenance, Long lifespan over 15years

Specification

400W

Model	MINI400W-3Plus	MINI400W-5Plus
Rated power	400 watts at 12 m/s
Max Capacity	450watts
Voltage	12, 24 VDC
Blades	3 Pcs Nylon Fiber	5 Pcs Nylon Fiber
Start-Up Wind Speed	2.0 ( m/s)	1.5 ( m/s)
Cut-In Wind Speed	2.5(m/s)	2.0(m.s)
Rotor Diameter	1.16 m	1.21m
Weight	6.2 kg	7.1 kg
Shipping Dimensions	790x 430x 220 mm (8 kg)	790x 430x 220 mm ( 9.3 kg)
KWH per Month	30KWh at 3.2 m/s	42KWh at 3.2 m/s
Mount	1.9 inch (48 mm) OD pipe
Turbine Controller (Plus)	Microprocessor-based smart internal regulator with Maximum Power Point Tracking,MPPT
Body	Cast aluminum
Overspeed Protection	Electronic torque control
Working temperature	—40℃~ 150℃
Certificate	ISO9001:2008 ,CE, Rohs
Survival Wind Speed	50 m/s
Warranty	3 year limited warranty

600W,800W,1200W,1600W

Model	MAX 600W	MAX 800W	MAX 1200W	MAX 1600W
Rated power	600W	800W	1200W	1600W
Max power	750W	950W	1300W	1800W
Rated voltage	24 VDC	48 VDC	48VDC/110VDC	48VDC/110VDC
Rated current	25A	16.7A	25A/10.9A	33A/14.5A
Rated Rpm	650
Rated wind speed	12m/s
Blades	5 Pcs Nylon Fiber glass
Start-Up Wind Speed	1.5 ( m/s)	1.5 ( m/s)	2.0 ( m/s)	2.0 ( m/s)
Cut-In Wind Speed	2.0 (m/s)	2.0 (m/s)	2.5 (m/s)	2.5 (m.s)
Rotor Diameter	1.7 m	1.8 m	2.0 m	2.2 m
N.W	28.5KG	30KG	36KG	41KG
G.W	33KG	35.5KG	41KG	46KG
Shipping Dimensions	*1690540290mm*	*1690540290mm*	*1890540290mm*	*1890540290mm*
Mount	Flange connection
Turbine Controller	MPPT wind solar hybrid controller
Body	Cast aluminum
Overspeed Protection	Electromagnetic & blade aerodynamic braking
Working temperature	—40℃~ 150℃
Certificate	ISO9001:2008 ,CE, Rohs
Survival Wind Speed	50 m/s
Warranty	3 year limited warranty

Details

Easy to install

Projects

are windly used for home use,marine,hybrid power system,communication project...etc

Workshop

Packaging & Shipping

Model	MINI400W-3PLUS	MINI400W-5PLUS
Weight	6.2 kg	7.1 kg
Shipping Dimensions	790x 430x 220 mm (8 kg)	790x 430x 220 mm ( 9.3 kg)
KWH per Month	30KWh at 3.2 m/s	42KWh at 3.2 m/s
Mount	1.9 inch (48 mm) OD pipe
Warranty	3 year limited warranty
packing	Cartons for exporting with EPE protection

Our Services

Why choose us?

1.Partner of F.A.O.
2. Professional experience of serving wind&solar products for more than 6 years.
3.Specialized in the series of products supporting services.
4. Quality is the first.

Certifications
