Help Center2014 New Arrival Wind System, Mini Wind Power Generator for Home
Related Products
-
2014 New Arrival Low Noise Wind Turbine Wind Turbine 220vUS$ 200 - 400MOQ: 1 Piece -
2014 New Arrival Home Use Windmills Home, Wind Mill Power GeneratorUS$ 200 - 400MOQ: 1 Piece
-
New Arrival 300w-1600w Wind Turbine Model, Wind Turbines Prices, Newsky Wind TurbineUS$ 200 - 400MOQ: 1 Piece
-
Nylon WindmillUS$ 200 - 400MOQ: 1 Piece
-
2014 New Arrival Home Use Small Wind Generator TurbineUS$ 200 - 400MOQ: 1 Piece
Specifications
wind system, mini wind power generator for home1,Bearing from "SKF"
2,Easy installation,
3.ce,rohs
wind system, mini wind power generator for home
models of wind system, mini wind power generator for home
300w,400W, 600W, 800W, 1200W, 1600W
Features of wind system, mini wind power generator for home
♦ Bearing: Sweden SKF
♦ Stainless steel screw bolt: Brand THE
♦ 100% Primary aluminum housing, not secondary aluminum
♦ Low start-up wind speed
♦ High-efficient Generator
♦ Perfect Wind Wheel System
♦ Unique Design Of The Rudder
♦ Damp-proof, sand-proof, Anti-rust, Anticorrosion
♦ Easy installation, Free of maintenance, Long lifespan over 15years
Specification of wind system, mini wind power generator for home
400W
Model |
MINI400W-3Plus |
MINI400W-5Plus |
Rated power |
400 watts at 12 m/s |
|
Max Capacity |
450watts |
|
Voltage |
12, 24 VDC |
|
Blades |
3 Pcs Nylon Fiber |
5 Pcs Nylon Fiber |
Start-Up Wind Speed |
2.0 ( m/s) |
1.5 ( m/s) |
Cut-In Wind Speed |
2.5(m/s) |
2.0(m.s) |
Rotor Diameter |
1.16 m |
1.21m |
Weight |
6.2 kg |
7.1 kg |
Shipping Dimensions |
790x 430x 220 mm (8 kg) |
790x 430x 220 mm ( 9.3 kg) |
KWH per Month |
30KWh at 3.2 m/s |
42KWh at 3.2 m/s |
Mount |
1.9 inch (48 mm) OD pipe |
|
|
Turbine Controller (Plus)
|
Microprocessor-based smart internal regulator with Maximum Power Point Tracking,MPPT |
|
Body |
Cast aluminum |
|
Overspeed Protection |
Electronic torque control |
|
Working temperature |
—40℃~ 150℃ |
|
Certificate |
ISO9001:2008 ,CE, Rohs |
|
Survival Wind Speed |
50 m/s |
|
Warranty |
3 year limited warranty |
|
600W,800W,1200W,1600W
Model |
MAX 600W |
MAX 800W |
MAX 1200W |
MAX 1600W |
Rated power |
600W |
800W |
1200W |
1600W |
Max power |
750W |
950W |
1300W |
1800W |
Rated voltage |
24 VDC |
48 VDC |
48VDC/110VDC |
48VDC/110VDC |
Rated current |
25A |
16.7A |
25A/10.9A |
33A/14.5A |
Rated Rpm |
650 |
|||
Rated wind speed |
12m/s |
|||
Blades |
5 Pcs Nylon Fiber glass |
|||
Start-Up Wind Speed |
1.5 ( m/s) |
1.5 ( m/s) |
2.0 ( m/s) |
2.0 ( m/s) |
Cut-In Wind Speed |
2.0 (m/s) |
2.0 (m/s) |
2.5 (m/s) |
2.5 (m.s) |
Rotor Diameter |
1.7 m |
1.8 m |
2.0 m |
2.2 m |
N.W |
28.5KG |
30KG |
36KG |
41KG |
G.W |
33KG |
35.5KG |
41KG |
46KG |
Shipping Dimensions |
1690*540*290mm |
1690*540*290mm |
1890*540*290mm |
1890*540*290mm |
Mount |
Flange connection |
|||
Turbine Controller |
MPPT wind solar hybrid controller |
|||
Body |
Cast aluminum |
|||
Overspeed Protection |
Electromagnetic & blade aerodynamic braking |
|||
Working temperature |
—40℃~ 150℃ |
|||
Certificate |
ISO9001:2008 ,CE, Rohs |
|||
Survival Wind Speed |
50 m/s |
|||
Warranty |
3 year limited warranty |
|||
Projects Show of wind system, mini wind power generator for home
| Model | MINI400W-3PLUS | MINI400W-5PLUS |
| Weight | 6.2 kg | 7.1 kg |
| Shipping Dimensions | 790x 430x 220 mm (8 kg) | 790x 430x 220 mm ( 9.3 kg) |
| KWH per Month | 30KWh at 3.2 m/s | 42KWh at 3.2 m/s |
| Mount | 1.9 inch (48 mm) OD pipe | |
| Warranty | 3 year limited warranty | |
| packing | Cartons for exporting with EPE protection | |
Factory
Certifications
---------------------------------------------------------------
Why choose us?
1.Partner of F.A.O.
2. Professional experience of serving wind&solar products for more than 6 years.
3.Specialized in the series of products supporting services.
4. Quality is the first.
--------------------------------------------------------------
In response the call of government concerning on energy-saving & emissions reduction, we majorly focus on the development of wind solar power system. Based on radical innovatory design concept and high-tech application, make fully use of the green, clean energy to achieve zero power consumption, zero emissions, zero pollution.
Guided by the principle of “advanced technology,exquisite product and competent manufacturing”,the company is proceeding with the mission of energy saving and green planet building based on the spirit of credit,innovation,hard working and social responsibility.
