Help CenterQ485 Monorail Type Hanger Shot Blasting Machine
Related Products
-
Q378 Rotary Hook Type Hanger Shot Blasting Cleaning MachineUS$ 50,000 - 70,000MOQ: 1 Set -
QT37 Hanger Type Shot Blasting MachineUS$ 20,000 - 60,000MOQ: 1 Set
-
Hanger Chain Shot Peening Blasting MachineUS$ 20,000 - 60,000MOQ: 1 Set
-
Hanger Pass Through Type Shot Blasting MachineUS$ 35,000 - 80,000MOQ: 1 Set
-
Q38 Series of Hanger Chain Type Shot Blasting MachineUS$ 40,000 - 100,000MOQ: 1 Set
Specifications
1.Design based on requirments2.Prompt Delivery
3.Competitive Price
4.ISO 9001:2008
5.Overhead rail with quantity of hooks
Qingdao Antai Heavy Industry Machinery Co., Ltd.
Founded in 2003, 10 years experience for making shot blasting machine.
A group company,having real estate, machinery and leather bags industry.
Eight experienced engineers to consider every possibility for customers.
Three of them has over 25 years knowledge of shot blasting technology.
3D software for auxiliary design. Show every design details in front of you.
Experienced technicians for production, installation, commissioning & service.
ISO 9001:2008 certified company, CE certificate will be issued soon.
All machining parts out sourced from professional CNC machining company with strict quality control procedure.
Own foundry to produce special material spare parts for our machines.
Hanger shot blasting machine, hanger sand blasting machine
Ring shape rail shot blasting machine is widely used in foundry plant, forging plant, metal processing.
The tunnel type machines are designed to increase the performance of the hook type machines by keeping the turbines continuously running.
The materials are hanged on several hooks connected to a ring type overhead conveyor, which can be monorail, double rail or with hoists.
The hook inside the blasting room, once in position, starts to rotate on its axis and move back and forward in front of the turbines (mounted on one side of the machine). These combined movements ensure the complete shot-blasting of the parts external surface.
The customer can choose the size and loading capacity of the machine according to the parts to be shot-blasted.
Technical Specification:
Model: Q485
1. Size of parts: Φ1000*1500 mm
2. Load capacity of one hook: 500 Kg
3. Quantity of blast wheel: 6 sets
4. Turbine motor power: 15 Kw * 6
5.Abrasive flow rate: 250*6 Kg
6. Digital control panel or PLC controller
7. Overhead rail: Ring shape
8. Dust collector: bag type dust collector or Cartridge type
9. Door opening: pneumatically or electrically controlled
10. Installation power: 150 Kw (without dust collector)
11. Number of hooks: 15 pcs
12. Noise level: <90dB
