Germany brand 5A phocos charge controller 8A price solar charge controller solar charge controllerIntelligent Timer Functions
Germany brand 5A phocos charge controller 8A price solar charge controller solar charge controller features
• Battery State-of-Charge display with 3 LEDs
• Acousticload disconnect pre-warning
• PWM-regulation(series type)
• Boost,Equalizeand Float charging, also for VRLA
• Automatic12/24 V detection
• Integratedtemperature compensation
• Largeterminals(up to 16 mm2 wire size)
• SOC and voltage controlled LVD
• Fully electronically protected
Germany brand 5A phocos charge controller 8A price solar charge controller solar charge controller specification
Type |
CML 05 |
CML 08 |
CML 10 |
CML 15 |
CML 20 |
System voltage |
12/24 V auto recognition |
||||
Max. charge/load current |
5 A |
8 A |
10 A |
15 A |
20 A |
Floatcharge |
13.7/27.4 V (25 °C) |
||||
Boostcharge |
14.4 /28.8 V (25 °C), 2 Std. activation: battery voltage < 12.3/24.6 V |
||||
Equalization |
14.8/29.6 V (25 °C), 2 Std. activation: battery voltage < 12.1/24.2 V |
||||
Deep discharge protection: State of charge dependent Voltage dependent Reconnect level |
11.4 – 11.9 V / 22.8 – 23.8 V 11.0/22.0 V 12.8/25.6 V |
||||
Overvoltage protection |
15.5/31.0 V |
||||
Undervoltage protection |
10.5/21.0 V |
||||
|
Max. panel voltage (Overvoltageprotection by varistor) |
30 V in 12 V system 50 V in 24 V system |
||||
|
Temperaturecompensation (Charge voltage) |
−25 mV/K at 12V −50 mV/K at 24V |
||||
Max. self consumption |
< 4 mA |
||||
Grounding |
positive grounding possible |
||||
Ambienttemperature |
−40 to +50 °C |
||||
Max. height |
4,000 m above sea level |
||||
Batterytype |
lead acid (GEL, AGM, flooded) |
||||
Wire cross section |
< 16 mm2 |
||||
Weight |
160 g |
||||
Dimensions (W x H x D) |
80 x 100 x 32 mm |
||||
Type of protection |
IP22 |
||||
Germany brand 5A phocos charge controller 8A price solar charge controller solar charge controller pictuers
Germany brand 5A phocos charge controller 8A price solar charge controller solar charge controller package
