Specifications
Germany solar battery charge controller solar panel charge controller mini solar charge controller3years warranty
12/24Vauto
Germany solar battery charge controller solar panel charge controller mini solar charge controller features
• Can be ordered with one output as on-off switch and
anotherasoutputwithdimmerfunction(CIS)ortwo
on-off switches (CIS-2L)
• Corrosion-proof epoxy-encapsulated PCB (IP68)
• Compactsize
• Infraredremote control programming accessory (CU)
• Intelligenttimerfunctionsavailable for lighting control
• Four-stagebattery charging (main, float, boost, equalizati- on), temperature compensated
• Automaticsystem voltagerecognition(12/24V)
Germany solar battery charge controller solar panel charge controller mini solar charge controller
specification
Type |
CIS 05 CIS-2L 05 |
CIS 10 CIS-2L 10 |
CIS 20 CIS-2L 20 |
System voltage |
12/24 V auto recognition |
||
Max. charge/load current |
5 A |
10 A |
20 A |
Floatcharge |
13.8/27.6 V (25 °C) |
||
Main charge |
14.4/28.8 V (25 °C), 30 min. (daily) |
||
Boostcharge |
14.4/28.8 V (25 °C), 2 h Activation:battery voltage < 12.3/24.6 V |
||
Equalization |
14.8/29.6 V (25 °C), 2 h Activation:battery voltage < 12.1/24.2 V (at least every 30 days) |
||
|
Deep discharge protection: Cut-off voltage Reconnectlevel |
11 – 12 V / 22 – 24 V 12.8/25.6 V |
||
Overvoltage protection |
15.5/31.0 V |
||
Undervoltage protection |
10.5/21 V |
||
|
Max. panel voltage (Overvoltageprotection by varistor) |
55 V |
||
|
Temperaturecompensation (Charge voltage) |
−25 mV/K at 12 V −50 mV/K at 24 V |
||
Max. own consumption |
5 – 8 mA at 12 V 6 – 10 mA at 24 V |
||
Grounding |
Positive grounding possible |
||
Ambienttemperature |
−40 to +60 °C |
||
Max. altitude |
4,000 m above sea level |
||
Batterytype |
Leadacid (GEL, AGM, flooded) |
||
Adjustmentrange: Evening/morninghours Night/day detection |
0 – 15 h / 0 – 14 h 2.5 – 10 V |
||
Wire length |
10 cm |
||
Dimensions (W x H x D) |
82 x 58 x 20 mm |
||
Weight |
150 g |
||
Wire cross section |
1.5 mm2 |
1.5 mm2 |
2.5 mm2 |
Type of protection |
IP68 (1.5 m, 72 h) |
||
solar battery charge controller solar panel charge controller mini solar charge controller
pictuers
Germany solar battery charge controller solar panel charge controller mini solar charge controller
package
