HD Video Conferencing With 30x High Quality Products

HD Video Conferencing With 30x High Quality Products thumbnail-1
HD Video Conferencing With 30x High Quality Products photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Simultaneous Interpretation:
No
Place of Origin:
Guangdong, China
Brand Name:
Oneking
Contact Supplier Request Quote Chat Now
Shenzhen Oneking Technologies Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Simultaneous Interpretation No
Place of Origin Guangdong, China
Brand Name Oneking
Model Number HD830-DSY-SN7500

Specifications

HD video conferencing
Work & Standby LED indicator
RS-232C/VISCA Protocol
Private Tooling design
Boundary scanning

HD video conferencing  with 30x High quality products



Product Description



Features:

  • Private Tooling  design High Definition PTZ camera
  • Fast and smooth video handling
  • Power ON-OFF switch
  • Work & Standby LED indicator
  • Speed Match
  • Auto/Manual focus/brightness/WB
  • RS-232C/VISCA Protocol
  • Lens/Dome OSD
  • Boundary scanning
  • Standby & wakeup status
  • Swap video format
  • DVI/HDMI Video output

Performance:

  • 1920x1080pixels progressive @30fps
  • 30x optical, 12x digital zoom
  • F=4.3-129mmF1.6-4.7
  • HOV 63.7 degree
  • 1/2.8” Type Exmor CMOS 2.14 Mega Pixel Sensor
  • Pan ±177.5 degree
  • Tilt +90 degree, -45degree
  • 64 preset positions
  • 4 cruise lines
  • DC 12V, 2A

Dimension:

  • L 250mm x W 140mm x H154mm
  • N. Weight: 2.6kgs
  • G. Weight: 4.8kgs

Installation:

  • Desktop
  • Ceiling mount
  • Standard Tripod accessory
Our Services



Model No.

HD830-DSY-SN7500

Sensor

Image Sensor

1/2.8" Type Exmor CMOS

Effective Pix

2.14 Megapixel

Min. Illumination

0.05Lux

White balance

Auto/Manual

Gain control

Auto/Manual

Backlight compensation

On/Off

Shutter speed

1/1 - 1/10,000S

S/N ratio

>50db

Lens

Focus

f=4.3-129mmF1.6-4.7

Iris

Auto/Manual

Lens

30 Optical x 12 digital zoom

Horizontal view angle

63.7

Video output

HDMI, HD-SDI, DVI , YPbPr, CVBS

Signal system

1080P@60,1080P@50,

1080P@30,1080P@25,
1080i@60,1080i@50,
720P@60,720P@50

Control terminal

EIA/RS232C,EIA/RS485(Bidirectional)

Control Protocol

VISCA,PELCO-D

baud rate

9600/38400bps

patrol line

4 cruise sequence

preset position

64 preset positions

Speed Match

Pan/Tilt movement speed depends on camera module zoom in/out

OSD Menu

Access to OSD Menu and adjust camera module parameters

Image auto flip

Support Horizontal/Vertical image flip

Pan movement speed

1-200°/Second

Tilt movement speed

1-150°/Second

Pan movement range

Pan: 0-355°

Tilt movement range

Up: 90°, Down: 45°

Pan scanning automatically

Support Pan scanning automatically

Boundary scanning

0-355°(programmable)

Remote controller

IR Wireless Remote controller P/T/Z

Power supply

DC12V,2A

Work Temperature

0-50°C

Humidity

0-95%RH

LxWxH

250mm x 140mm x 154mm

Weight

1380g

Accessories kits in package:

  • 1x HD 830-DSY Video Camera
  • 1x DC 12V/2A Power Adaptor
  • 1x User’s manual
  • 1x3m USB 3.0 Cable
  • 1x Installation brackets & screws
  • 1xIR Remote Controller





Packaging & Shipping





 HD video conferencing with 30x High quality products



Company Information





We are the professional manufacturer of Color Video Full HD PTZ Camera----

  • Business Type: Manufacturer, Trading Company
  • Main Products:  Network Camera, Mini PTZ Camera, Vandal Proof PTZ Camera, HD PTZ Speed Dome Camera, HD Video Conference Camera
  • Location:  Guangdong, China (Mainland)
  • Year Established:2005
  • Year start exporting: 2005
  • Number of Employees: 101 - 200 People
  • Total Revenue: US$2.5 Million - US$5 Million
  • Main Markets:  Southeast Asia, Northern Europe, Western Europe, South Asia, Mid East
  • Certifications: ISO9001
  • Product Certifications: CE
  • Average Lead Time: 4 Day(s)HD video conferencing with 30x High quality products
