High quality conference web camera with 3.27MP 20 Optical Zoom

Specifications

1. Conference web camera.
2. Natural and smooth video images.
3. High-quality video display.

High quality conference web camera with 3.27MP 20 Optical Zoom



• USB 3.0 Interface
• Private Tooling  design High Definition PTZ camera
• Fast and smooth video handling
• Power ON-OFF switch
• Work & Standby LED indicator
• Speed Match
• Auto/Manual focus/brightness/WB
• RS-232C/VISCA Protocol
• Lens/Dome OSD
• Boundary scanning
• Standby & wakeup status
• Swap video format key

Performance:

• 1920x1080pixels progressive @30fps
• 20x optical, 12x digital zoom
• F=4.7-90mmF1.6-3.5
• HOV 55.4 degree
• 1/2.8” Type ExmorCMOS 3.27 Mega Pixel Sensor
• Pan ±177.5 degree
• Tilt +90 degree, -45degree
• 64 preset positions
• 4 cruise lines
• DC 12V, 2A

Dimension:

• L 250mm x W 140mm x H154mm
• N. Weight: 2.6kgs
• G. Weight: 4.8kgs

Installation:

• Desktop
• Ceiling mount
• Standard Tripod accessory

Model No.		HD820-U30-K3
Image Sensor	Image Sensor	1/2.8" Type Exmor CMOS
	Effective Pix	3.27 Megapixel
	Min. Illumination	0.1Lux
	White balance	Auto/Manual
	Gain control	Auto/Manual
	Backlight compensation	On/Off
	Shutter speed	1/1 - 1/10,000S
	S/N ratio	>50db
Lens	Focus	f=4.7-90mmF1.6-3.5
	Iris	Auto/Manual
	Lens	20 Optical x 12 digital zoom
	Horizontal view angle	59°
Video output		USB 3.0
Signal system		1080P@30,1080P@25, 1080i@60,1080i@50, 720P@60,720P@50 ,
Control terminal		EIA/RS232C,EIA/RS485(Bidirectional)
Control Protocol		VISCA,PELCO-D
baud rate		9600/38400bps
patrol line		4 cruise sequence
preset position		64 preset positions
Speed Match		Pan/Tilt movement speed depends on camera module zoom in/out
OSD Menu		Access to OSD Menu and adjust camera module parameters
Image auto flip		Support Horizontal/Vertical image flip
Pan movement speed		1-200°/Second
Tilt movement speed		1-150°/Second
Pan movement range		Pan: 0-355°
Tilt movement range		Up: 45°, Down: 45°
Pan scanning automatically		Support Pan scanning automatically
Boundary scanning		0-355°(programmable)
Remote controller		IR Wireless Remote controller P/T/Z
Power supply		DC12V,2A
Work Temperature		0-50°C
Humidity		0-95%RH
size		250mm x 140mm x 154mm
Weight		1380g

• 1x HD 820 Video Camera
• 1x DC 12V/2A Power Adaptor
• 1x User’s manual
• 1x3m USB 3.0 Cable
• 1x Installation brackets & screws
• 1xIR Remote Controller
