Factory price semi-automatic blowing machine with CE
HTII-5L
Model |
|
HTII-5L |
Max. Product Volume |
(L) |
5L |
Dry cycle |
(pc/h) |
700*2 |
Screw Diameter |
(mm) |
70 |
Screw L/D ratio |
(L/D) |
25 |
Screw drive power |
(KW) |
22 |
Screw heating capacity |
(KW) |
6.2~8.2 |
No. of heating zone |
(ZONE) |
3 |
Max. Output of HDPE |
(Kg/hr) |
70 |
Oil pump drive power |
(KW) |
7.5 |
Clamping force |
(KN) |
60 |
Platen distance |
(mm) |
148~508 |
Mold moving stroke |
(mm) |
400 |
Max. Size of Mold(W*H) |
(mm) |
370*390 |
Max. Die diameter |
(mm) |
145 |
Die heat capacity |
(KW) |
2.5 |
No. of heating zone |
(ZONE) |
3 |
Central distance of Double head |
(mm) |
160,180 |
Blowing pressure |
(Mpa) |
0.6 |
Air volume |
(M3/MIN) |
0.4 |
Cooling water pressure |
(Mpa) |
0.2~0.3 |
Water consumption |
(L/MIN) |
60 |
Size of machine ( L*W*H) |
(m) |
3.43*2.3*2.65 |
Weight of machine |
(TON) |
5.5 |
semi-automatic blowing machine
Extruson blow molding machine suppliers of main parts:
a) Hydraulic Parts
Name |
Supplier |
Oil Pump |
PARKER or SUNNY, America |
Valve |
YUKEN or SUNNY |
Hose, Joint |
PARKER SIR |
Sealer |
Top DZ Europe |
b) Electrical Parts
Name |
Supplier |
Microcomputer Control System |
MITSUBISHI PLC, Japan |
Touch Screen |
HITECH color screen, Taiwan |
Temperature Controller |
MITSUBISHI, Japan |
Conductor |
SCHNEIDER |
Air Switch |
SCHNEIDER |
Motor |
SIMENS BEIDE Asynchronous Motor |
Power Resource |
MEAN WELL, Taiwan |
Inverter |
MITSUBISHI |
c) Pneumatic Parts
Name |
Supplier |
Solenoid Valve |
FESTO, Germany |
Cylinder |
FESTO, Germany |
Suzhou Tongda Mould Co., LTD is located in zhangjiagang city TangQiao economic development zone and the traffic is developed.
The company fusion technology, Western Europe professional design and production, sales three categories and 23 kinds of series and one hundred and eighteen kinds of specifications and types of automatic bottle blowing machines, blow molding blow molding machines and the company is in jiangsu province beverage, plastic machinery enterprise one of the export base.
The company product widely sales Britain, Australia, Brazil and 55 countries and the area, deeply trusted by customers domestic and abroad.
semi-automatic blowing machine
1> The machine will be tested and checked at our workshop before delivery.
2>After one year, we will supply accessories are provided only one the cost price.
3>Free production technology and process configuration.
4>Installation: Experts’ team to buyer’s country after confirmation that the goods arrived in site and civil works completed get ready for installation. Funds for trip need to be payed by client and extra salary $60/day during the engineer’s journey.
5>Warranty: One year from the date of Installation or acceptance of the Plant whichever comes first
6>We will reply you within 24 hours
