graphite plate
- 1100000 Piece / Pieces per Month
- shanghai
- T/T
- IG-010 Double layer tinplate Single sided tanged sheet graphite composite sheet
- IG-009 tinplate Single sided tanged sheet graphite composite sheet
- IG-008 multi-layer stainless steel wire mesh graphite composite sheet
- IG-007 Reinforced Graphite Composite Sheet with multi-layer stainless steel (304 l, 316 l) tanged sheet
- IG-006 multi-layer tinplate tanged sheet graphite composite sheet
- IG-005 graphite reinforced composite sheet (lined with stainless steel wire mesh)
Product Details
Place of Origin: | Shanghai, China | Brand Name: | KS-FAFA-66 | Model Number: | kessen |
Type: | Composite Sheet | Application: | industry | Thickness: | 50mm |
Grade: | Industrial Grade | C Content (%): | 55% |
Product Description
Specifications
1,large size and thin thickness2,easy to be splicing
3,high purity graphite materials
4,high quality but competitive pric
Specifications
1,large size and thin thickness
2,easy to be splicing
3,high purity graphite materials
4,high quality but competitive price
graphite plate
Shap and sizes
production according to customers' requirements
Advantages;
1,high strength,high hardness
2,good heat-resistance, low porosity
3,anti-abrasion,anti-scour
4,antioxidation,non-infiltrantion
strictly production:
• one-body graphite with thin thickness, large sizes and splicing graphite plates.
• anti-oxidation, impermeability or strengthening treatments.
• completely according to customers' needs.
•timely delivery
Grade | Item | Unit | Reference Data | Main Application |
regular | Bulk density | g/cm3 | ≤0.045 | Vibrated graphite in mainly in round and square shape. 1-used to machine graphite crucible,boat/dish,mold,rotor an shaft,heating unit,launder, and graphite densener and son on. 2-used as structural material in high temperature furnace. 3-used as blank materials of machined graphite parts in environment of strong erosion. such as industries of rare earth, chemicals and so on 4-used to machine graphite electrodes. |
Specific Resistivity | µΩm | 1.55-1.60 | ||
Flexural Strength | Mpa | ≥8.0 | ||
Elastic Modulus | GPa | ≤9.0 | ||
C.E.T(100-600°C) | -10-6/°C | 2.0-2.6 | ||
Ash | % | ≤0.30 | ||
one impregnated and two baked | Bulk density | g/cm3 | 1.63-1.70 | |
Specific Resistivity | µΩm | 5.5-6.8 | ||
Flexural Strength | Mpa | ≥11.0 | ||
Elastic Modulus | GPa | ≤11.0 | ||
C.E.T(100-600°C) | -10-6/°C | 1.8-2.2 | ||
Ash | % | ≤0.30 | ||
two impregnated and three baked | Bulk density | g/cm3 | 1.66-1.73 | |
Specific Resistivity | µΩm | 4.6-6.2 | ||
Flexural Strength | Mpa | ≥13.0 | ||
Elastic Modulus | GPa | ≤15.0 | ||
C.E.T(100-600°C) | -10-6/°C | 1.2-1.8 | ||
Ash | % | ≤0.30 |
