China high quality fiber glass scheelite Spiral Conveyor Chutes
Jiangxi walker mining machinery is a metallurgical mineral processing machinery enterprise which has been specialized in researching, manufacturing, sales and tracking service since 1985. Our products have been exported to Russia, Australia, Mongolia, Vietnam, Thailand, Sudan, Ghana, South Africa, Peru, ect.
Jiangxi walker mining machinery had joint the mining exhibition in Mongolia, Russia in 2013. We will join the exhibition in Ghana, South Africa in 2014. If you are in these countries, welcome to go to our booth.
Our Services
- Mining project consulting.
- Design and draw flowchart.
- Testing sample in laboratory
- Providing whole production line equipments.
- Dispatching engineer overseas guidance for equipments installation and testing.
- Training your local first batch workers.
- Help you to solve the problems during the equipment operation.
- Spare parts provided
- OEM is acceptable. We can produce the equipment as per your design or draft.
- Water recycle system can be designed for you
Main Structure of Spiral Conveyor Chutes :
Types of Spiral Conveyor Chutes :
3-5 truns for one start, 2-4 starts for one spiral
Model |
5LL-1500 |
5LL-1200 |
5LL-900 |
5LL-600 |
5LL-400 |
|
Outside dia(mm) |
1500 |
1200 |
900 |
600 |
400 |
|
pitch(mm) |
540,720 |
900,720,540 |
675,540,405 |
450,360,270 |
240,180 |
|
Pitch Dia Ratio |
0.75,0.6,0.45 |
0.75,0.6,0.45 |
0.75,0.6,0.45 |
0.75,0.6,0.45 |
0.6,0.45 |
|
Lateral slope |
9° |
9° |
9° |
9° |
9° |
|
Maximum starts per column |
4-2 |
4-2 |
4-2 |
2 |
2 |
|
Feeding Size (mm) |
0.3-0.02 |
0.3-0.03 |
0.3-0.03 |
0.2-0.02 |
0.2-0.02 |
|
Feeding Density(%) |
25-55 |
25-55 |
25-55 |
25-55 |
25-55 |
|
Capacity(T/H) |
8-6 |
4-6 |
2-3 |
0.8-1.2 |
0.15-0.2 |
|
|
External Size |
Length (mm) |
1560 |
1360 |
1060 |
700 |
460 |
Width (mm) |
1560 |
1360 |
1060 |
700 |
460 |
|
Height (mm) |
5230 |
5230 |
4000 |
2600 |
1500 |
|
Weight (Kg) |
800 |
600 |
400 |
150 |
50 |
|
