Elevator Control Pcb Board

Name: Elevator Control Pcb Board
Brand: SHENYIXIN
SKU: 110265257
Availability: InStock

US$ 0.1 - 5 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

SHENYIXIN

Model Number:

SYX-YP8335NT

Shenzhen Shenyixin Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name SHENYIXIN

Model Number SYX-YP8335NT

Number of Layers 10-Layer

Base Material FR4

Copper Thickness 1oz

Board Thickness 1.6mm

Min. Hole Size 0.3mm

Min. Line Width 0.076mm

Min. Line Spacing 0.076mm

Surface Finishing Plating Gold

Specifications

1.UL,ROHS,ISO,SGS,Layer:1-12 PCB
2.12 years experience in PCB
3.Drill Size:0.1mm,Line:3mil pcb
4.100%E-Test

This product is made of fr4 material,it is suitable for electronic production circuit boards.

If you send us your Gerber Files and PCB specification, we will quote for you within 2 hours. We will try our best to satisfy with you!

Why do you choose us?

1. We have 15 years experience professional PCB manufacturer.

2. Competitive price and high quality of PCB.

3. We offer copying and sampling service.

4. Solder marks types are according to your requirement. (Any colors are available.)

Our Factory Manufacture Capability

Item	Manufacture Capability
Material	FR-4 / Hi Tg FR-4 / Lead free Materials (RoHS Compliant) /CEM-3, Aluminum, Metal based
Layer No.	1-- 12
Finished Board thickness	1.6 mm-4.0mm’(60 mil-160 mil)
Board Thickness Tolerance	±10%
Cooper thickness	1 OZ-3OZ (36 um-110 um)
Copper Plating Hole	18-40 um
Impedance Control	±10%
Warp &Twist	0.50%
Peelable	0.012"(0.3mm)-0.02’(0.5mm)
Images
Min Trace Width	0.076mm (3mil)
Min Space Width	0.076mm (3mil)
Min Annular Ring	0.1mm (4 mil)
Solder Mask
Min Solder Mask Dam	0.0635 mm (2.5mil)
Solder mask Clearance	0.1mm (4 mil)
Holes
Min Hole size (CNC)	0.1 mm (4 mil)
Min Punch Hole Size	0.9 mm (35 mil)
Hole Size Tol (+/-)	PTH:±0.075mm;NPTH: ±0.05mm
Hole Position Tolerance	±0.075mm
Plating
HASL	2.5um
Lead free HASL	2.5um
Immersion Gold	Nickel 3-7um Au:1-5u''
OSP	0.2-0.5um
Certificate	ROHS, SGS, UL, ISO9001: 2008.
