Help CenterMulti-function Power Meter
Related Products
Specifications
1.LCD display2.Harmonics measurement
3.Energy pulse output,RS485 communication,data collection,analog output
4. programmable
Introduction
YD2200 is a powerful Multi-function Power Meter to measure and display all the parameters as well as harmonics content, with 4 expansion plug-ins: RS485 comms, digital input/output, energy pulse, and DC4-20mA output, so as to meet all kinds of demands.
Measurement
Voltage (Ph-Ph/Ph-N)
Current (Ph-Ph/Ph-N)
Active Power
Reactive Power
Apparent Power
Frequency
Power Factor
Harmonics
Total harmonics content of voltage (Ph-Ph)
Total harmonics content of current (Ph-Ph)
3rd-19th harmonics content of voltage (Ph-Ph) (RS485 output)
3rd-19th harmonics content of current (Ph-Ph) (RS485 output
Maximum Value
Max. instantaneous value (V, I)
Max. instantaneous value (±Kwh, ±Kvah)
Max. instantaneous value (S)
Computation Energy Pulse(Expansion)
Import active energy YM-E2 provides 2 energy pulse
Export active energy outputs.
Import reactive energy Active/Reactive Energy Pulse output
Export reactive energy 0.1-100000kWh/one pulse (option) Dry contact output (1A*100V).
Pulse Output (option)
One pulse output, active energy/reactive energy
Pulse constant: 5000/kWh.
Photocoupler output(0.1A*30V).
Measuring Range
30-600V
0-6A
45-65Hz
Accuracy
Frequency: 0.1%
Voltage: 0.2%±0.1V
Current: 0.2%±0.001A
Power: 0.5%±0.4W
Power Factor0: .5%±0.001 -1-0-1
Energy: 1.0%
Display
Green back-lit LCD,5 displays.6 operational keys.
Communication
Expansion Module YM-485 provides RS-485 port,ModBus-RTU protocol; 32(128) meters are connected as a network.
Data Acquisition (Expansion)
Each YM-K2 module collects 2 routs of dry contacts and accumulates the counting.
Control (Expansion)
Each YM-K2 provides 2 relay outputs, which can be controlled by communication, remote control or by some measured parameter.
Analog Output (Expansion)
Each YM-A20 provides 2 DC4-20mA outputs, corresponding to some parameter.
System
3P4W
3P4W BAL
3P3W
3P3W BAL
1P2W
1P3W
Programmable
Measuring System :3P4W/3P3W etc.
Transformation Ratio:PT; CT
Comms.Add. (1-247);Baud rate (1200-19200);Parity bit (N/E/O)
RTC:Year/Month/Day/Hour/Minute/Second
Energy:Reset
Dimension
Mounting Panel:96x96mm
Thickness:20mm
Depth:52mm(without module) ;
80mm with module
Mounting
Panel Mounting
Hole :92x92mm
Power Supply (AC/DC)
A85-265V or
DC85 330V (Standard)
DC18-90V (Optional)
Power Consumption) :< 4VA
Working Conditions
Temp.:-15-55
Humid: 20-95% (without condensation)
