Specifications
10.4 inch screen screen1.Material:Aluminum
2.Pure Flat
3.DUAL CORE
1041L 10.4" LCD Desktop Touch_Flat All-In-One
Perfect Interactive touch system of Desktop Solution
10.4 inch screen screen
1.Long lasting product cycle-enclosure
2. Multi-touch Projected Capacitive Flat Screen Touch panel ,
3.230-nit brightness (LCD panel)
Specifications
Case/Bezel Color |
Silvery or Black |
|
Display Size |
10.4" |
|
LCD Type |
TFT LCD |
|
Aspect ratio |
4:3 |
|
Useful Screen Area |
211 mm x 158 mm |
|
Touch panel |
Multi-touch Projected Capacitive Flat Screen |
|
Touch response time |
10.5ms (typical) |
|
Touch Monitor Dimensions |
368x 309x237 mm |
|
Optimal (native) Resolution |
800 x 600 |
|
LCD panel Pixel pitch |
0.264 x 0.264 mm
|
|
LCD panel Colors |
16.2 million |
|
LCD panel Brightness |
230 cd/m2 |
|
LCD panel Response Time |
8 ms |
|
|
Viewing Angle (typical, from center) |
Horizontal (left/right)
|
±60° or 120° total |
Vertical (up/down) |
35°(up), 65°(down) or 100° total |
|
Contrast Ratio |
500:1 |
|
Output Interface |
Mini D-Sub 15-Pin VGA type/ Audio/Mic |
|
Input Interface |
USB*3 |
|
Net |
Wifi and 3G Card(optional) |
|
Camera pixel |
2M,5M(optional) |
|
Power Supply Type |
Internal Battery DC 12V 10A(optional) |
|
External AC to DC power brick | ||
Monitor input: +12VDC ±5%,3.0 A; DC Jack (2.5) | ||
AC to DC power brick input: 100-240 VAC, 50/60 Hz | ||
|
Power dissipation: 40W max
| ||
|
ECM (Embed Computer Modul) |
ECM1: Intel® processor P7500 (1.8GHz Dual Core); ECM2: Intel® processor P7550 (2.26GHz Dual Core); HardDisk:320G;Rom:2G(DDR3,max6G); Operation System:Win7XpVistaLinux ECM3: Android A8 1.5G, Flash 4G ECM4: Android dual core 2G, Flash 4G Operation System: 4.04 |
|
Temperature |
Operating: 0°C to 40°C ;Storage -20°C to 60°C |
|
Humidity (non condensing) |
Operating: 20%-80%; Storage: 10%-90% |
|
Shipping Carton Dimensions |
490 x 440 x340 mm |
|
Weight (approx.) |
Actual: 6 kg ;Shipping: 8.5 kg |
|
Warranty Monitor |
3 years(Except for LCD panel 1 year) |
|
Backlight lamp life: typical 50,000 hours to half brightness | ||
Agency Approvals |
CE/FCC Rohs |
|
Mounting Options |
75 mm and 100mm VESA mount |
|
