Help Center10.4 Inch LCD Touch Panel PC With Car PC
Related Products
Specifications
10.4 Inch LCD Touch Panel PC With Car PC1.10.4" touch screen,lcd monitor
2.optional AV,TV.speaker,CE,R
1041L 10.4" LCD Desktop Touch_Flat All-In-One
Perfect Interactive touch system of Desktop Solution
10.4 Inch LCD Touch Panel PC With Car PC
1.Long lasting product cycle-enclosure
2. Multi-touch Projected Capacitive Flat Screen Touch panel ,
3.230-nit brightness (LCD panel)
Main use:
can be widely used for different service,such as
puter display
2.Food service
rmation Kiosks
for vending machine
5.gaming
6.ATM machine
7.other systems need touch
8. Touch Panel PC With Car PC
Specifications
Case/Bezel Color |
Silvery or Black |
|
Display Size |
10.4" |
|
LCD Type |
TFT LCD |
|
Aspect ratio |
4:3 |
|
Useful Screen Area |
211 mm x 158 mm |
|
Touch panel |
Multi-touch Projected Capacitive Flat Screen |
|
Touch response time |
10.5ms (typical) |
|
Touch Monitor Dimensions |
368x 309x237 mm |
|
Optimal (native) Resolution |
800 x 600 |
|
LCD panel Pixel pitch |
0.264 x 0.264 mm
|
|
LCD panel Colors |
16.2 million |
|
LCD panel Brightness |
230 cd/m2 |
|
LCD panel Response Time |
8 ms |
|
|
Viewing Angle (typical, from center) |
Horizontal (left/right)
|
±60° or 120° total |
Vertical (up/down) |
35°(up), 65°(down) or 100° total |
|
Contrast Ratio |
500:1 |
|
Output Interface |
Mini D-Sub 15-Pin VGA type/ Audio/Mic |
|
Input Interface |
USB*3 |
|
Net |
Wifi and 3G Card(optional) |
|
Camera pixel |
2M,5M(optional) |
|
Power Supply Type |
Internal Battery DC 12V 10A(optional) |
|
External AC to DC power brick | ||
Monitor input: +12VDC ±5%,3.0 A; DC Jack (2.5) | ||
AC to DC power brick input: 100-240 VAC, 50/60 Hz | ||
|
Power dissipation: 40W max
| ||
|
ECM (Embed Computer Modul) |
ECM1: Intel® processor P7500 (1.8GHz Dual Core); ECM2: Intel® processor P7550 (2.26GHz Dual Core); HardDisk:320G;Rom:2G(DDR3,max6G); Operation System:Win7XpVistaLinux ECM3: Android A8 1.5G, Flash 4G ECM4: Android dual core 2G, Flash 4G Operation System: 4.04 |
|
Temperature |
Operating: 0°C to 40°C ;Storage -20°C to 60°C |
|
Humidity (non condensing) |
Operating: 20%-80%; Storage: 10%-90% |
|
Shipping Carton Dimensions |
490 x 440 x340 mm |
|
Weight (approx.) |
Actual: 6 kg ;Shipping: 8.5 kg |
|
Warranty Monitor |
3 years(Except for LCD panel 1 year) |
|
Backlight lamp life: typical 50,000 hours to half brightness | ||
Agency Approvals |
CE/FCC Rohs |
|
Mounting Options |
75 mm and 100mm VESA mount |
|
