2239E 22" Wide LCD Open-frame Touchmonitor
vga cga lcd monitor for game
1.Long lasting product cycle-enclosure
2. High quality panel with 160° x 160° or 178° x 178°(option) viewing angle
3. 1000:1 contrast ratio, and 300-nit brightness (LCD panel)
4.Optional front mount and rack mount bezels
5.Future generation panels phased-in without external changes
Applications
Kiosk information system /Gaming and amusement /Light industrial shop-floor automation
Accessories
1.VGA Video Cable(DVI Cable is optional) 2.User Manual (English only)
3.Power Cord (US, EU or UK type) 4.Serial or USB cable
5.Power Brick
Specifications
Case/Bezel Color |
Steel/black |
||
Display Size |
22.0" Wide |
||
LCD Type |
TFT LCD |
||
Aspect ratio |
16:10 |
||
Useful Screen Area |
474mm x 296mm |
||
Touch panel |
Securetouch screen(SAW) |
||
|
Surface Durability
|
Surface durability is that of glass, Mohs' hardness rating of 7
|
||
Touch interface |
Dual Serial / USB |
||
Touch response time |
10ms (typical) |
||
Touch Monitor Dimensions |
526.0 x 345.0 x 54mm |
||
Optimal (native) Resolution |
1680 x 1050 |
||
LCD panel Pixel pitch |
0.282x 0.282 mm
|
||
Plug and Play |
VESA DDC 1/2B |
||
LCD panel |
LCD parameter |
High LCD parameter (option) |
|
LCD panel Colors |
16.7 million |
16.7 million |
|
LCD panel Brightness |
300 cd/m2 |
300 cd/m2 |
|
LCD panel Response Time |
5 ms |
20 ms |
|
|
Viewing Angle (typical, from center) |
Horizontal (left/right)
|
±80° or 160° total |
±89° or 178° total |
Vertical (up/down) |
±80° or 160° total |
±89° or 178° total |
|
Contrast Ratio |
1000:1 |
1000:1 |
|
Input Video signal connector |
RGB Analog Video and DVI Video (optional) |
||
Input sync format |
31.5-80.0 kHz 60-75 Hz |
||
Power Supply Type |
External AC to DC power brick |
||
Monitor input: +12VDC ±5%,4.0 A; DC Jack (2.5) | |||
AC to DC power brick input: 100-240 VAC, 50/60 Hz | |||
|
Power dissipation: 48W max
| |||
On-screen display(OSD) |
Controls(back):PowerMenuUpDownAuto; Settings: contrast , brightness, H/V position; RGB(color temp), clock ,phase , recall; Languages: English, German, French ,Spanish, Japanese; |
||
Temperature |
Operating: 0°C to 40°C; Storage -20°C to 60°C |
||
Humidity (non condensing) |
Operating: 20%-80%; Storage: 10%-90% |
||
Shipping Carton Dimensions |
556x456x206mm |
||
Weight (approx.) |
Actual:8 kg; Shipping: 10kg |
||
Warranty Monitor |
3 years(Except for LCD panel 1 year) |
||
Backlight lamp life: typical 50,000 hours to half brightness | |||
Agency Approvals |
CE/FCC/Rohs |
||
Mounting Options |
75 mm or 100 mm VESA mount |
||
1.Optional:ODM, OEM,
2.Skype: touchdisplays.sales2 (You are welcome to adding my skype for a timely discussion online)
3.Touch screen technology:
Resistive TouchScreen(7"-22"), SAW TouchScreen,(15"-32")Projected Capacitive TouchScreen(10"-32"), Infrared TouchScreen(24"-100")
4.All of our products have 3 years(Except for LCD panel 1 year) warranty .
5.Track the order until you get the goods.
6.All our products are inspected strictly by our QC department before delivery.
