Help CenterGravity Equipment Spiral Chute Separator for Zircon Beneficiation
Related Products
-
Factory Supply Froth Flotation Machine With CE ApprovedUS$ 10,000 - 999,999MOQ: 1 Set -
Shanghai Sulphur Spiral Chute Design for Ore SeparationUS$ 1,000 - 99,999MOQ: 1 Set
-
China Leading Brand High Frequency Vibrating Screen SupplierUS$ 1,000 - 999,999MOQ: 1 Set
-
Long Using Life Shaking Table From Lipu ChinaUS$ 1,000 - 999,999MOQ: 1 Set
-
Gold Mining Equipment Vibrating Chutes Gravity Spiral ChuteUS$ 1,000 - 99,999MOQ: 1 Set
Specifications
Spiral Chute Separator:1.Model:5LL series;
2.Capacity:0.2-40t/h;
3.Height:1.5-6.6m;
4.Application:iron, stannum, tungsten.
Features of Spiral Chute Separator:
1.Simple structurer;
2.Light weight, lower power consumption;
3.Easy operation, reliable operation, easy maintenance;
4.Smaller area, high capacity, and high separating efficiency.
Structure of Spiral Chute Separator :
Spiral chute is mde of feeder, feed chute, spiral flute, bracket, intercepting slot, and supporting frame,etc.
Application of Spiral Chute Separator :
Spiral is used to process iron, stannum, tungsten, tantalum. niobium, gold ore, colliery, monazite, rutile and zircon of the size btween 0.3 and 0.02mm, metals and nonmetal minerals with enough proportion deviation.
Technical Parameters of Spiral Chute Separator :
| Model | Helix No. | Cycle | Feed Size(mm) | Feed Density(%) | Capacity(t/h) | Area(m2) | Height (m) |
| 5LL400 | 1-2 | 4-5 | 0.02-2 | 30-50 | 0.5-0.2 | 0.25 | 1.5 |
| 5LL600 | 1-2 | 4-5 | 0.02-2 | 30-50 | 0.8-1.2 | 0.5 | 2.6 |
| 5LL900 | 2-3 | 4-5 | 0.03-3 | 30-50 | 2-3 | 1.2 | 3.2 |
| 5LL1200 | 2-4 | 4-5 | 0.03-3 | 30-50 | 4-6 | 2 | 5.23 |
| 5LL2000 | 2-4 | 3-5 | 0.04-4 | 20-45 | 15-40 | 5.7 | 6.6 |
Any change of technical parameters, there is no further notice.
Working Principle of Spiral Chute Separator :
