Help CenterMineral Beneficiation Processing Spiral Chute Separator With Best Price
Related Products
-
Copper Ore Machine Spiral Chute Design With Best PriceUS$ 1,000 - 99,999MOQ: 1 Set -
Best Seller and Widely Used Gravity Spiral Chute for Construction in ChileUS$ 1,000 - 99,999MOQ: 1 Set
-
BV Certificate High Frequency Desliming Screen for Medicine Powder SievingUS$ 1,000 - 999,999MOQ: 1 Set
-
Concentrate Machine Wet Shaking Tables Separation With High Stroke FrequencyUS$ 1,000 - 999,999MOQ: 1 Set
-
Iron Sand Spiral Chute Price With Simple Structure on Hot SaleUS$ 1,000 - 99,999MOQ: 1 Set
Specifications
Spiral Chute Separator :1.Model:5LL series;
2.Capacity:0.2-40t/h;
3.Height:1.5-6.6m;
4.Application:iron, stannum, tungsten.
Features of Spiral Chute Separator :
1.Simple structurer;
2.Light weight, lower power consumption;
3.Easy operation, reliable operation, easy maintenance;
4.Smaller area, high capacity, and high separating efficiency.
Structure of Spiral Chute Separator :
Spiral chute is mde of feeder, feed chute, spiral flute, bracket, intercepting slot, and supporting frame,etc.
Application of Spiral Chute Separator :
Spiral is used to process iron, stannum, tungsten, tantalum. niobium, gold ore, colliery, monazite, rutile and zircon of the size btween 0.3 and 0.02mm, metals and nonmetal minerals with enough proportion deviation.
Technical Parameters of Spiral Chute Separator :
| Model | Helix No. | Cycle | Feed Size(mm) | Feed Density(%) | Capacity(t/h) | Area(m2) | Height (m) |
| 5LL400 | 1-2 | 4-5 | 0.02-2 | 30-50 | 0.5-0.2 | 0.25 | 1.5 |
| 5LL600 | 1-2 | 4-5 | 0.02-2 | 30-50 | 0.8-1.2 | 0.5 | 2.6 |
| 5LL900 | 2-3 | 4-5 | 0.03-3 | 30-50 | 2-3 | 1.2 | 3.2 |
| 5LL1200 | 2-4 | 4-5 | 0.03-3 | 30-50 | 4-6 | 2 | 5.23 |
| 5LL2000 | 2-4 | 3-5 | 0.04-4 | 20-45 | 15-40 | 5.7 | 6.6 |
Any change of technical parameters, there is no further notice.
