LIPU High Reliable Operation and Low Energy Consumption Jaw Crusher for Sale

Name: LIPU High Reliable Operation and Low Energy Consumption Jaw Crusher for Sale
Brand: LIPU
Availability: InStock

FOB Price

USD $1,000 - $200,000 / Set

1 Set(Min.Order)

Supply Ability 90 Set / Sets per Month
Port Qingdao Dalian Shanghai for jaw crusher for sale export
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other, Jaw Crusher, Jaw Crusher for Sale
Application	Ore crushing,construction,building materials, Ore,stone mining,metallurgical,construction,smelting,hydraulic	Motor Type	AC Motor
Power(W)	30000-220000	Capacity(t/h)	20-1100
Place of Origin	Shanghai, China	Brand Name	LIPU
Model Number	PEV series and PE series	Dimension(LWH)	According to different capacities
Weight	8.5-112t	Certification	BV,CE,ISO9001-2008 Certs
Warranty	One Year	After-sales Service Provided	Engineers available to service machinery overseas

Packaging Details

Standard container or as customers' requirements.(jaw crusher for sale)

Product Description

LIPU High Reliable Operation and Low Energy Consumption Jaw Crusher for Sale

Brief Introduction of Jaw Crusher for Sale:

Jaw crusher is suitable for crushing middle and high hardness materials such as various ores, slags, concrete and etc.It has been extensively used in coarse crushing,intermediate crushing & fine crushing in many areas such as mining,metallurgy,cement,ceramic,chemical,refractory material,building material and water conservancy industries.

Performance Features of Jaw Crusher for sale:

1.Symmetrical V-type crushing chamber optimizes and maximizes inlet size,crushing ration and capacity.Compared to traditional jaw crusher,capacity increased more than 30%;

2.Larger bearing capacity&longer service life by adopting integrated bearing block,alloy hardening and tempering main shaft and larger bearing;

3.More reliable&easier to adjust outlet size by using adjusting wedges;

4.By installing motor on the frame,it saves installation space and extends V-belt service life;

5.More efficiently to reduce pressure on the base as rubber damping block replaces foundation bolt;

6.Processing steadier by perfectly combination of kinetics parameters and structural design.

Working Principle of Jaw Crusher for Sale:

The motor transmits power through belt,drives the moving jaw to do periodic motion towards the fixed jaw by the eccentric shaft.The angle between toggle plate and moving jaw plate increases when moving jaw moves.So the moving jaw moves towards the fixed jaw.The stuff will be crushed in this process.The angle between toggle plate and moving jaw decreases when moving jaw moves down,the moving jaw moves leaves fixed jaw by pulling rod and spring,the final crushed stuff will be discharged from the outlet.

Technical Parameters of Jaw Crusher for Sale:

Model	Max Input size (mm)	Outlet size (mm)	Capacity (t/h)	Power (kW)	Overall dimension L×W×H(mm)	Weight (t)
PEV400×600	340	40-80	20-65	30-37	2500×1750×1950	8.5
PEV500×750	425	45-150	45-107	45-55	3100×1980×2290	11.5
PEV600×900	510	75-180	100-200	55-75	3450×2360×2780	17
PEV750×1100	640	80-190	140-320	90-110	3750×2580×3180	24
PEV860×1100	730	100-200	200-500	110-132	4870×2850×3170	32
PEV900×1200	760	100-220	220-600	110-132	3500×2850×3290	48
PEV1000×1200	850	150-300	280-750	132-160	4700×2930×3460	52
PEV1200×1500	1020	180-340	350-950	160-220	6380×5310×3710	83
PEV1500×1800	1250	210-360	500-1100	280	7460×6240×4250	122
PEV250×1000	210	25-50	20-50	30-37	1680×2050×1370	7
PEV250×1200	210	25-50	25-65	37-45	1680×2180×1370	8
PEV300×1300	250	20-90	30-105	55-75	2150×2390×1590	11

Producing Process of Jaw Crusher for Sale:

Delivery Site of Jaw Crusher for Sale:

Work Site of Jaw Crusher for Sale:
