Help CenterReliable Operation Flotation Machine for Lead,Plumbum,Copper Concentrating From Shanghai
Related Products
-
Quality Circular Vibrating Screen For Quartz Sand Beneficiation From ShanghaiUS$ 1,000 - 999,999MOQ: 1 Set -
LIPU Brand Flotation Machine For Solid-liquid SeparationUS$ 10,000 - 999,999MOQ: 1 Set
-
Longer Working Life Spiral Sand Washing Machine From ShanghaiUS$ 1,500 - 9,999MOQ: 1 Set
-
Slurry Mixing Agitator For Beneficiation ProcessUS$ 1,000 - 999,999MOQ: 1 Set
-
LIPU Iron Sand Magnetic Separator in Mine for Wet or DryUS$ 1,000 - 99,999MOQ: 1 Set
Specifications
Lipu Brand flotation machine:1.XJK,SF series;
2.Large inhaling capacity;
3.Capacity:0.05-3.5t/h;
4.DiaOf impeller:200-650mm
Specifications of reliable operation flotation machine :
1.XJK,SF flotation machine
2.Large inhaling capacity
3.Capacity:0.05-3.5t/h
4.DiaOf impeller:200-600mm
Application of reliable operation flotation machine :
flotation machine for zinc ore can be used to separate non-ferrous metal, ferrous metal, noble metal, non-metallic mine, chemical material. It can be used in roughing, scavenging, selection or reverse flotation. In the flotation process, after being mixed with drug, some qualified mineral attaches on bubble, floats on the surface of slurry and is scraped out, other mineral still stays in the slurry, so the separating purpose is finished.
The impeller is rotated by V-belt of motor and produces negative pressure by centrifugal function. Enough air is sucked to mix slurry, and slurry mixes drug at the same time. Mineral sticks on bubble completely and floats on the surface of slurry to form mineralized bubble. Useful bubble is scraped out by adjusting flashboard height and controlling liquid surface.
Reliable operation flotation machine Features:
1.Large inhaling capacity and low consumption.
2. Complete flotation circuit with inhaling air and slurry, no auxiliares are needed.
3. Process is easy to be changed.
4. Reasonable circulation of slurry decreases coarse sand sedimentation.
5. Automatic controlling device makes adjustment more convenient.
Types of reliable operation flotation machine :
We have various of High Efficiency Flotation Machine,such as XJK-0.13(1A), XJK-0.23(2A), XJK-0.35(3A), XJK-0.62(4A), XJK-1.1(5A),XJK-2.8(6A) etc. In order to give you a responsible quotation, you can inform us the following
information:
1. What’s the material you are going to deal with?
2. What’s the granularity of the material?
3. What’s the granularity of the final products are you going to achive?
4. What’s the producing capacity you are going to achieve?
Our engineers will suggest you the most suitable one for you according to your information.
Reliable operation flotation machine Parameter:
| Type and specification | Trough volume of the machine | Dia. Of impeller | Production capacity m2/msh | Revolution of the impeller r/min | Scraper revolution r/min |
| XJK-0.13(1A) | 0.13 | 200 | 0.05-0.16 | 600 | 17.5 |
| XJK-0.23(2A) | 0.23 | 250 | 0.12-0.28 | 500 | 17.5 |
| XJK-0.35(3A) | 0.35 | 300 | 0.18-0.4 | 470 | 17.5 |
| XJK-0.62(4A) | 0.62 | 350 | 0.3-0.9 | 400 | 16 |
| XJK-1.1(5A) | 1.1 | 500 | 0.6-1.6 | 330 | 26 |
| XJK-2.8(6A) | 2.8 | 600 | 1.5-3.5 | 280 | 26 |
After-Sale Service:
Erection and Commissioning
Operator Training
Spare Parts Supply
Warranty Terms: More than 12 months
Delivery Time:25~30 days after receiving advanced payment
Products Certificate: CE, ISO9001:2000
We(Shanghai LIPU Heavy Industry Co.,Ltd) believe that you can rely on us as we provide you quite satisfactory service and products with best quality at most competitive price in the world. We are very happy if you do not hesitate to send us any of your inquiries and we will always give satisfactory services.
Looking forward to hearing from you at your convenience!
