Specifications
PV MCU Controller 12V 10A /CE/MANSON/Microprocessor control PWM with 3 stage charging algorithmsThe SBC-7100 Series PV charge controller is designed for use with all types of photovoltaic panels and different types of batteries, such as wet or sealed lead acid, lead calcium, lead anitomny battery.
The MCU (Microprocessor controller) is programmed with 3 stage charging algorithms and with 0~100% PWM ( Pulse Width Modulation) duty cycles to provide the fastet, optimal charging current and voltages from PV panels according to the actual state of charge and type of battery.
The 3-stage (Bulk, Absorption, Float) and *Equalization* charging cycles ensure complete charging cycles and maintenance of elac acid battery automatically. Bulk and Float threshold charge voltage levels are user adjustable to meet specific batter manufacturer's recommendation. *Equalization Charging is only for Wet type leac acid Battery, automatically cycples once a month for 2 hours. Equalization Charging can be de-activated or re-activated manually. Hence, maximum PV charging efficiency and longer the servie life span of the battery are ensured. Ampere Hour logging read outs in three sets, today and last two days are shown on the LCD. This is useful to check the condition of PV data for efficiency and actual capacity of your system. Electronic Blocking of back current to PV and overcharging battery protection are standard.
Features
- User adjustable charging voltages
- Suitable for all types of lead acid batteries.
- Microprocessor control PWM with 3 stage charging algorithms
- Bulk, Absorption, Float stage, PV charging current , Battery voltage on LCD display.
- Ampere Hour logging read outs of 3 days.
- 5 state LED indications of battery levels with reference to PV voltage.
- Electronic Overcharge Protection & blocking current from battery to PV panel
- Over Temperature Protection of controller's electronic circuit
- 10 slectable Night Light programs
- User defined battery low voltage disconnect adn reconnect for load terminal
- Optional remote temperature sensor for battery to provide precise right charging
- Optional remote signal/control terminal for synchronization fo unit's load terminal.
