weighing indicator XK3190-A27E
Introduction
XK3190 - A27E applicable to electronic platform scales, electronic platform scale, electronic ground value, such as using 1 ~ 4 350 Ω sensor static weighing system.
Standard function
Single window 2 inches specially highlight LED display, the real "big eyes"
Peak maintain and average display pieces
Pieces of manual accumulation and automatic accumulation
Mixer level 4 battery indicator, under-voltage alarm and automatic shutdown function
Upper and lower alarm function, HIGH - OK - LOW status indication
Mixer auto sleep function
Tare mixer preset
10 pieces precision ratio automatic zoom function
High precision analog-to-digital conversion technology, readability is 1/30000
Pieces of random configuration 6 v / 4 ah maintenance-free storage battery, can charge the battery randomly
Equipped with RS - 232 - c communication port, baud rate is optional
Mixer equipped with big screens communication port, 20 ma current loop connection mode
Technical parameters
Accuracy level: level 3
Largest verification points degree: 3000
The input signal range: - 19 ~ mv mv
Conversion speed: 10 times per second
Pieces of nonlinear 0.0015% or less
For the bridge voltage: DC 5 v
Sensor connection: 1 ~ 4 only 350 Ω sensor
Dividing value: 1/2/5/10/20/50 optional
Communication interface: RS232 serial port, 20 ma current loop (constant current source) signal big screen interface.
Power supply: AC220V;50 and 60 hz (2% ~ 2%)
Temperature: - 10 ° ~ 40 ° C C
Storage temperature: - 25 ° C ~ 55 ° C
Big screen interface:
Serial output signal output way:, current loop signal.
Baud rate: 600
Transmission distance: 200 m or less
Serial communication interface
Mixer RS232C way
Baud: 600/1200/9600/600/1200 are optional
Transmission distance: 30 or less
Package and Delivery
DeliveryUsually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
Our Company:
Silvanus Electric Manufacture (Yixing) Co., Ltd. is a professional hi-tech enterprise, which specializes in manufacturing high precision load cells.
On the basis of strong R&D ability and advanced equipment in production, inspection and testing, we specialize in scientific research, production and sales of all kinds of high precision load cells. Our products are widely used in electric weighing apparatuses, metallurgy, petrifaction, environmental protection, mechanism, textiles, medicines, construction examining, and ports.
We insist on the policy of "customer oriented" and aim at producing the best load cells. In controlling and managing the quality of our products. We comply with OIML and ISO9001:2000 standards. According to the quality policy of "Through building a system of quality and management which is lasting and effective", we serve customers with better quality products on time. We will always improve ourselves and bring our company a brand-new future.
| Transportation | Routine |
| By car | 3 hours from Shanghai to Yixing |
| By high speed railway | 2 hour from Shanghai(or Shanghai Hongqiao) railway station to YiXing railway station,then we will pick you up.It will take 10 mins by car from Yixing railway station to our company. |
