weighing indicator XK3190-T8
weighing indicator Introduction
YH - T8 stainless steel instrument suitable for: electronic platform scales, electronic platform scale, electronic ground value, such as using 1 ~ 4 350 Ω sensor static weighing system.
weighing indicator Standard function
Pieces of single window multi-function LCD display window
Peak keep function in pieces
Pieces of livestock scale function
Mixer external serial printing function
Pieces more than the unit switch function (kg/lb/t)
Pieces of manual accumulation and automatic accumulation
Tare mixer preset functions
Upper and lower alarm function, HIGH - OK - LOW status indication
Mixer level 4 battery indicator, under-voltage alarm and automatic shutdown function
Mixer automatic dormancy and multistage power saving mode
Mixer multistage backlight brightness control
10 pieces precision ratio automatic zoom function
High precision analog-to-digital conversion technology, readability is 1/30000
Mixer can use four section 5 alkaline battery or nickel metal hydride rechargeable batteries
Pieces can be used for international certification ac adapter power supply
Pieces of optional RS - 232 - c and RS485 communication port, baud rate is optional
Optional big screen communications port, 20 ma current loop connection mode
weighing indicator Technical parameters
Accuracy level: level 3
Largest verification points degree: 3000
The input signal range: - 19 ~ mv mv
Pieces of each test the minimum input voltage dividing Δ Umin 1 mu V
Conversion rate: 80 times/SEC or less
Nonlinear: 0.0015% or less
For the bridge voltage: DC 5 v
Sensor connection: 1 ~ 4 only 350 Ω sensor
Dividing value: 1/2/5/10/20/50 optional
Communication interface (optional) : the RS - 232 - c and RS485 communication, 20 ma current loop (constant current source) big screen interface
Power supply: AC 100 ~ 240 v.50 ~ 60 hz (ac adapter)
DC 4 ~ 6 V (optional section 4 5 alkaline batteries or rechargeable batteries)
Temperature: - 10 ° ~ 40 ° C C
Storage temperature: - 25 ° C ~ 55 ° C
Big screen interface (optional) :
Serial output signal output way:, current loop signal.
Baud rate: 600
Transmission distance: 2000 m or less
Serial communication interface (optional)
Mixer RS232C way and RS485
Baud: 600/1200/9600/600/1200 are optional
Transmission distance: 30 meters or less (RS232C way)
1000 meters or less (RS485)
Package and Delivery
DeliveryUsually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
Our Company:
Silvanus Electric Manufacture (Yixing) Co., Ltd. is a professional hi-tech enterprise, which specializes in manufacturing high precision load cells.
On the basis of strong R&D ability and advanced equipment in production, inspection and testing, we specialize in scientific research, production and sales of all kinds of high precision load cells. Our products are widely used in electric weighing apparatuses, metallurgy, petrifaction, environmental protection, mechanism, textiles, medicines, construction examining, and ports.
We insist on the policy of "customer oriented" and aim at producing the best load cells. In controlling and managing the quality of our products. We comply with OIML and ISO9001:2000 standards. According to the quality policy of "Through building a system of quality and management which is lasting and effective", we serve customers with better quality products on time. We will always improve ourselves and bring our company a brand-new future.
