anti-explosion indicator XK3190-BXA12E
Anti-explosion Weighing Indicator Introduction
BXK3190 - A12E flameproof design was adopted for the main structure of all input and output interface (into the sensor, keyboard, etc.) is used in the design, has passed the certification of national instruments explosion-proof safety, applicable to any flammable and explosive gas environment using the platform scale instrumentation.Adopting high precision analog-to-digital conversion technology and special software anti-vibration technology, ac/dc.
Anti-explosion Weighing Indicator Standard function
High precision A/D conversion, readability is 1/30000
Calling code display is convenient, farmar, alternative sense of observation and analysis of tolerance
Special software technology, enhance the system's ability to resist vibration
Zero tracking range and scope of zeros (boot/manual), can be set up respectively
Digital filtering speed, amplitude and the stable time can be set up
With weighing counting functions;(for power-off protection)
Can be random charging;With undervoltage directives and protection
Random configuration 6 v / 4 ah maintenance-free battery
Equipped with RS - 232 communication port, baud rate is optional, optional communication way
Anti-explosion Weighing Indicator Technical parameters
Precision grade: 3 grades.
Max verification division:3000
High precision A/D conversion with readability 1/30000
Input-signal range: -19mV~19mV
Nonlinear:≤0.0015%
Power supply: DC 5V
Load cell connection: able to connect 1~4 350Ω load cell.
Division:1/2/5/10/20/50(selectable)
Display: main/auxiliary display both for 6 digits LED, character height: 2 inch,15 status instruction lights
Data transportation port(optional):RS-232C,20 mA current loop for scoreboard.
Power supply: AC 220V / 50~60Hz
DC 6V/4Ah(Lead-acid battery inside)
Operation temperature: -10 ℃~40 ℃
Storage temperature:-25 ℃~55 ℃
Scoreboard interface(optional)
Signal output method: serial output, current loop signal.
Baud rate:600
Distance of scoreboard signal transportation:≤200M
Serial communication interface(Optional)
RS232C,Baud rate:600/1200/2400/4800/9600 selectable
Distance of RS232 signal transportation:≤15
Package and Delivery
DeliveryUsually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
Our Company:
Silvanus Electric Manufacture (Yixing) Co., Ltd. is a professional hi-tech enterprise, which specializes in manufacturing high precision load cells.
On the basis of strong R&D ability and advanced equipment in production, inspection and testing, we specialize in scientific research, production and sales of all kinds of high precision load cells. Our products are widely used in electric weighing apparatuses, metallurgy, petrifaction, environmental protection, mechanism, textiles, medicines, construction examining, and ports.
We insist on the policy of "customer oriented" and aim at producing the best load cells. In controlling and managing the quality of our products. We comply with OIML and ISO9001:2000 standards. According to the quality policy of "Through building a system of quality and management which is lasting and effective", we serve customers with better quality products on time. We will always improve ourselves and bring our company a brand-new future.
