weighing indicator XK3190-DM1
Introduction
Double LED Display Weiging Indicator XK3190-A28E is widely applied in electronic platform scale,electronic floor scale and so on alike static weighing system equipped with 1~4 350Ωload cell.
Standard function
High precision A/D conversion, readability 1/50000;
Calling code display is convenient, farmar, alternative sense of observation and analysis of tolerance;
Zero tracking range, zero (boot/manual) range can be set up respectively;
Dividing value automatically switch: can choose double degree weighing through parameter Settings;
Nonlinear correction and dynamic speed compensation function;
Automatic/manual, unconditional/conditions, the daily report/classification statistical reports print Settings;
Fast filling type weighing singles printing function Settings;
Weighing record storage/check/delete/power-off protection;
Provide the location code input Chinese characters and the upper machine to download two Chinese character input mode;
Equipped with RS - 232 / RS422 (optional) communication port, baud rate is optional, optional communication mode;
RS422 method support computer with more than one meter networking functions;
Equipped with big screens communication port, 20 ma current loop (constant current source);
Equipped with standard parallel print interface, can be connected or 24 9 needle line printer.
Can localization to print all kinds of Chinese goods name, customer name, name of enterprise unit and note item in Chinese;
According to the standard or custom print single transverse and vertical duplicate and record format and so on the many kinds of weighing documents;
(M1P) built-in high speed micro play Chinese characters;
Adopt photoelectric isolation and so on the many kinds of anti-interference measures of protection instrument has better anti-jamming;
Instrument to mention
Appearance:
Technical parameters
A/D conversion way: Σ - Δ transformation way
A/D conversion rate: 200 times/SEC
Maximum number of A/D conversion: 24 bit
Input signal range: 15 ~ 30 mv mv
The input sensitivity: 1 mu V/e or higher
Sensor for bridge power: DC5V;I 250 ma or less;
Connect the sensor number: can take eight 350 Ω sensor
Sensor connection mode: 6 wire, long term automatic compensation, compensation distance of 50 meters or less
Verification points degree: 3000
Outside the biggest degree: 50000
Within the maximum resolution: 1000000
Dividing value: 1/2/5/10/20/50/100 is optional
Digital tube display mode: seven VFDS, seven state indicator
Display range: -
Package and Delivery
DeliveryUsually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
Our Company:
Silvanus Electric Manufacture (Yixing) Co., Ltd. is a professional hi-tech enterprise, which specializes in manufacturing high precision load cells.
On the basis of strong R&D ability and advanced equipment in production, inspection and testing, we specialize in scientific research, production and sales of all kinds of high precision load cells. Our products are widely used in electric weighing apparatuses, metallurgy, petrifaction, environmental protection, mechanism, textiles, medicines, construction examining, and ports.
We insist on the policy of "customer oriented" and aim at producing the best load cells. In controlling and managing the quality of our products. We comply with OIML and ISO9001:2000 standards. According to the quality policy of "Through building a system of quality and management which is lasting and effective", we serve customers with better quality products on time. We will always improve ourselves and bring our company a brand-new future.
| Transportation | Routine |
| By car | 3 hours from Shanghai to Yixing |
| By high speed railway | 2 hour from Shanghai(or Shanghai Hongqiao) railway station to YiXing railway station,then we will pick you up.It will take 10 mins by car from Yixing railway station to our company. |
