weighing indicator XK3190-D2
Introduction
XK3190 - D2 + series instrument functions are all the strong adaptability, is widely used in electronic ground value, electronic truck scale and static rail weighbridge used 1 ~ 8 sensor static weighing system.
Standard function
High precision A/D conversion, readability 1/30000;
Zero tracking range, zero (boot/manual) range can be set up respectively;
Automatic/manual, daily report/classification statistical reports print Settings;
Fast filling type weighing singles printing function Settings;
Storage 255 car number and the corresponding tare weight, 100, 512 groups of weighing the article number of records;
Weighing record storage/check/delete/power-off protection;
Artificial linear correction calibration;
Nonlinear correction of up to 5 points, reduce the limitation on the system accessories requirements;
Equipped with RS - 232 communication port, baud rate is optional, optional communication mode;
Equipped with big screens communication port, 20 ma current loop (constant current source) and RS - 232 two connection ways;
Equipped with standard parallel print interface, can be connected or 24 9 needle line printer.
D2 + P built-in 16 panel micro printer;
Recommend a non-standard manufacturing of varieties:
Rapid transverse joint filling type printing function of coating;
Overrun automatic record store, password delete function of coating;The <
Appearance:
Technical parameters
A/D conversion method: double integral type
A/D conversion rate: 50 times per second
Maximum number of A/D conversion: material 700000
Input signal range: 0 ~ 30 mv mv
The input sensitivity: 1 mu V/e or higher
Sensor for bridge power: DC15V;I ma 350 or less
Connect the sensor number: can take eight 350 Ω sensor
Sensor connection mode: 6 wire, long term automatic compensation, compensation distance of 50 meters or less
Verification points degree: 3000
Outside the biggest degree: 30000
Dividing value: 1/2/5/10/20/50/100 is optional
Digital tube display mode: six VFDS, six state indicator
Display range: - 99990 ~ 320000 (e = 10)
Package and Delivery
DeliveryUsually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
Our Company:
Silvanus Electric Manufacture (Yixing) Co., Ltd. is a professional hi-tech enterprise, which specializes in manufacturing high precision load cells.
On the basis of strong R&D ability and advanced equipment in production, inspection and testing, we specialize in scientific research, production and sales of all kinds of high precision load cells. Our products are widely used in electric weighing apparatuses, metallurgy, petrifaction, environmental protection, mechanism, textiles, medicines, construction examining, and ports.
We insist on the policy of "customer oriented" and aim at producing the best load cells. In controlling and managing the quality of our products. We comply with OIML and ISO9001:2000 standards. According to the quality policy of "Through building a system of quality and management which is lasting and effective", we serve customers with better quality products on time. We will always improve ourselves and bring our company a brand-new future.
