crane load indicator XK3190-H2B
Introduction
XK3190 H2B electrical suite USES Σ - Δ modulus conversion technology, with electronic crane scale hang components and shell, can form functional wireless electronic crane scale.
Kit includes: XK3190 - H2B portable weighing display, H2AD type A/D module, wireless data transmission, H2CDQ type intelligent fast charging machine, cadmium nickel battery and other accessories and parts of consumables.
Standard function
High precision A/D conversion, readability 1/30000;
Calling code display is convenient, farmar, alternative sense of observation and analysis of tolerance;
Keyboard calibration, parabolic method of nonlinear correction, calibration is convenient;
Has negative scale function and can be used for casting process;
Zero (boot/manual) range can be set up respectively;
Storage of 11 categories each record weighed 99;(weighing time, gross weight and net weight, etc.)
Weighing record storage power-off protection;
Random configuration 12 v / 1.6 AH nimh battery power supply;(instrument power supply)
Scale body with 12 v2200mah nickel cadmium battery power supply, can work continuously for 24 hours or more;
Quick charger with 5 kinds of protection mode of intelligence, effectively extend the service life of rechargeable batteries;
Equipped with RS - 232 / RS - 422/485 optional) communication port, baud rate, optional optional communication mode;
Equipped with big screens communication port, 20 ma current loop connection mode;
Equipped with standard parallel print interface, 24 pin line printer can be connected;
Built-in 16 panel micro printer, print, weighing list;
With extended interface, the inside can be extended functionality according to the special requirements of the users;
Technical parameters
A/D conversion way: Σ - Δ transformation way
A/D conversion rate: 6 times per second
Maximum number of A/D conversion: 20 bits
Input signal range: - 2 mv ~ 28 mv
The input sensitivity: 1 mu V/e or higher
Sensor for the bridge power supply: DC 5 v.I ma 50 or less;
Connect the sensor number: can meet four 350 Ω sensors
Sensor connection mode: four wire system
Verification points degree: 3000
Outside the biggest degree: 30000
Within the maximum resolution: 300000
Dividing value: 1/2/5/10/20/50 optional
Digital tube display mode: 8-bit LCD, 19 status indicator
Display range: - 30000 ~ 30000
Package and Delivery
DeliveryUsually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
