SW9800-T2
Weighing display controller (Stainless Steel Shell)
Application: various electronic scales and electronic platform scales
Main Technical Index
- Range of Input Signal: -39~+39mV
- A/D Conversion: 24-bit Sigma-Delta A/D Conversion
- A/D Sampling Frequency: 38.400 kHz
- Nonlinearity: ≤0.0015%F.S.
- Gain Error Drift: 1ppm/℃
- Minimum Resolution: 0.1µV/d
- Display Number of Division: ≤50000
- Supply Voltage: DC5V/150mA (can connect 10 sensors)
- Display: 6-bit 0.5 inch high-light LED display
- Serial communication interface: RS-232C
- Baud Rate: 1200/2400/4800/9600(optional)
- Printer: Serial interface can be connected with the thermal printer GP-5850II(optional)
- Operating Temperature: -10~+75℃
- Relative Humidity: ≤90%R.H
- Power Supply: DC10~37V, Built 6V/2.8Ah lead-acid batteries
- Power Dissipation: 2W
- External Dimension: 310×230×170mm
- Weight: 2.2kg
- Test Number of Division: 5000
Main Performance
- Filtering Progression Adjustment (Grade 1-4) and the T3.0 of Stabilization Control Procedure
- A/D transformation uniformity is good, and the sensor main line may longer
- Automatic Switching in 3 Graduations
- The cumulative total and automatic with manual function
- Automatic detection of battery,Low voltage alarm
- AC/DC, Built-in 6V battery
Package and Delivery
DeliveryUsually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
