Help CenterInternational Approval Plastic Weighing Display Indicator (sw201A)
Related Products
-
International Approval Plastic Weighing Display Indicator (CT600W)US$ 250 - 300MOQ: 1 Piece -
OIML Approval Plastic Weighing Display Indicator (CHB)US$ 38 - 48MOQ: 2 Pieces
-
Weighing Controller for Scale Control System Indicator Quality ChoiceUS$ 48 - 60MOQ: 1 Piece
-
OIML Electronic Digital Weighing Indicators (XSB5-AH) Quality ChoiceUS$ 38 - 48MOQ: 2 Pieces
-
Electronic Digital Weighing IndicatorsUS$ 38 - 48MOQ: 2 Pieces
|
Product introduction SW - 201 type is a specially developed weight transmitter which have both setting control technology and digital transmitting functions.It is a new type intelligent instrument can be applied to measuring control device for the metallurgical, petrochemical, cement, building materials, feed need ingredients.etc. Dimension and installation A Type Size:160*80*235mm Installation: Panel mounting hole size:152+1 ×76+1 (mm) B Type Size:259*103*210mm Installation: Panel mounting hole size: 249+1 ×93+1 (mm) Main function 1.Full board parameters setting function 2.With full digital calibration technology, which can calibrate the scale range automatically or manually Due to the high linearity, it can also automatically calibrated even if only load 20% F.S weight. 3.Three nonlinear correction function makes the system higher accuracy. 4.Functions of automatic zero, easy operation, ensure the accuracy of measurement (ingredients) 5.Four-way switch measures input/output, achieving constant value control 6.One way or two ways standard analog signal output (optional) both are available to facilitate the flexible application. 7.Optional serial data communication interface 8.Using EEPROM memory which hardware protection to protect the date even if the power is lost. 9.Using two-way isolation technology and special software to monitor circuit, with functions of program since the recovery. Adopt unique output protection circuit, good anti-jamming, can be used in harsh environment. 10. Measuring dynamic detection, date stabilizing processing. 11.Self-checking function which is advantageous for the instrument maintenance.
Technical parameter, specification and function
3.Communications interface (optional) One interface line for serial digital Signal types: standard RS - 232, RS - 485, 20mAa current loop (one-way). (Any type of above can be chosen and usd to same input interface computer and monitor)
4.Setting the control single Two road (normally open) relay contact: capacity AC250V 2.5 A
5.Display Main display 5 codes Red 0.8 inch LED Display weigh value and PROMPT Indicator light 8 LED display working state and content
6.General requirements and usage environment
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||
Delivery Usually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
Our Company:
Silvanus Electric Manufacture (Yixing) Co., Ltd. is a professional hi-tech enterprise, which specializes in manufacturing high precision load cells.
On the basis of strong R&D ability and advanced equipment in production, inspection and testing, we specialize in scientific research, production and sales of all kinds of high precision load cells. Our products are widely used in electric weighing apparatuses, metallurgy, petrifaction, environmental protection, mechanism, textiles, medicines, construction examining, and ports.
We insist on the policy of "customer oriented" and aim at producing the best load cells. In controlling and managing the quality of our products. We comply with OIML and ISO9001:2000 standards. According to the quality policy of "Through building a system of quality and management which is lasting and effective", we serve customers with better quality products on time. We will always improve ourselves and bring our company a brand-new future.
1.How to place an order?
Please provide us more details of what you want .
2.What terms of payment are available?
we accept T/T, L/C,Trade assurance,Western Union,etc.
3.When will you arrange the production?
we will arrange the production immediately after receiving your payment.
4.How do you ensure good product quality?
we have a complete quality control system ,all of our products are fully checked by IQC ,OQC departments before shipping to our clients.
