XSB-IC weighing controller Introduction:
XSB-IC, Weighing Controller is an all-purpose instrument, which is high-speed and high-accuracy. It has many special capabilities, which are well applied to weighing indicating and controlling applications. Besides, the functions of peak & valley detection and hold, and capability of positive and negative ambipolar signal process are well cooperate with
weighing controller Technical Datas
Range of input signal: |
±18;±37mV;±75mV;150mV |
Power supply |
220V AC,(9~30)V DC |
Operature Temperature |
-5℃~+50℃ |
Relative humidity |
90% RH |
External dimension |
96(W)×48(H)×125(L) |
Perfprate dimension |
92(W)×44(H) |
Load cell Exciting Voltage |
10V/150mA |
weighing controller Features:
1.16mm green LED of high radiance display.
2.Selectable indication of gross and net weight.
3.Functions of digital filtering,display graduation,indicating decimal point position hoices.
4.Auto Zero Tracking.
5.Accomplish the peak & the valley detecting and display.
6.Sampling & controlling rate is 50 times per second.
7.l on-off input can be used to zero clearing.
8.Optional interface boards:
—Standard RS232 or RS485 communication interface, connect a computer or printer.
—2 comparing outputs, with 6 selectable types
—Analog output
