auto body repair bench
The H-800 series of car collision repair system offers a unique first-class product which operators have no worries of work.It'smade of industrial and quality manganese steel which the surface andunder-surface plate are in the same thickness.6300mm length and 2200mmwidth platform will meets most collision repairing requirements.
It has an parallellift with 25ton lifting capacity loads cars easily,varies of openingeson the platform provide greater accessibility to the vehicle forrepairs,a faster and stronger anchoring system with fewer bolts tosecure the vehicle to the deck platform.
Tower with integratedroller bearing circumnavigate the platform smoothly and effortlessoperation.Variable-position pull collars provide for unlimitedpositioning for the correct pulls when making 10ton pulls at thehook.Overhead boom with patented wheel is quite useful for the highroof cars.
Plenty of striking and forged pulling accessories proof-tested with powerful strength.
Oneloading package includes winch,wheel stands,car dollies and secondarybag air jack,is a standard parts for H-800L & H-800M.
- Convenient and accurate measuring system in the industry.
- Most efficient pulling system in the world.
- Comprehensive vehicle database(Mitchell).
- Fast and easy anchoring clamp.
- National service support network.
Technical Data
| Parameters | Data |
| Platform length | 6300mm |
| Platform width | 2200mm |
| Platform height | 300-1500mm |
| Hydraulic pressure | 70Mpa(10000psi) |
| Max.pulling | 95KN(10Ton) |
| Pulling radius | 360° |
| Pneumatic | 0.8Mpa |
| Max. lifting weight | 3000KG |
| Total weight | 4100KG |
Parts No.
BB-800 Platform
BB-1 Pulling Tower(without overhead boom)
BB-2 Pulling Tower(with overhead boom)
BB-3 Ramps
BB-5 Main Clamp
HP-1 EGOR-PRO Hydraulic Pump (H-800C Equipped)
HP-2 USA Pump (ENERPAC,H-800L and H-800M Equipped)
RB-1 Roller Bridge
WB-1 Wheel Bracket
AJ-1 Air Secondary Jack(H-800L and H-800M Equipped)
MS-1 2-Dimesion Measuring System(with Mitchell Database)
BB-7 10pcs Pulling Tools Set(H-800C Equipped)
BB-9 20pcs Pulling Tools Set(H-800L and H-800M Equipped)
EW-1 Electric Winch
MPS-1 Multi-point Pulling System
UM-1 User Manual Book
Optional Parts No.
MS-2 3-Dimesion Measuring System(with Mitchell Database)
SC-1 Benz Special Clamp
SC-2 BMW Special Clamp
DHC-1005 Ball Pivot
DHC-1405 Trunk Clamp
DHC-1908 Fasten Clamp
MW-1 Manual Winch
