Scissor frame machine
The T-100 Mini Bench is very convenient and flexible which designed and manufactured for quick and small alignments.
Thelifting height from 120mm(min height) to 1400mm(upper bench edge) whichmeet most loading requirements.One 25-tons heavy-duty hydrauliccylinder installed on the scissor lift eliminate any doubts of liftingcapacity.
3400mm length and 880mm width frame can be applied for all along the frame vehicles.
Plenty of striking and forged pulling accessories proof-tested with powerful strength.
What's more,a standard 2-dimension measuring system helps operators measure vehicles easily and accurate.
- Most efficient pulling system in the world.
- Fast and easy anchoring clamp.
- 4 lifting pads are included.
- Comprehensive vehicle database(Mitchell).
- National service support network.
Technical Data
| Parameters | Data |
| Platform length | 3400mm |
| Platform width | 880mm |
| Platform height | 120-1400mm |
| Hydraulic pressure | 70Mpa(10000psi) |
| Max.pulling | 95KN(10Ton) |
| Pulling radius | 360° |
| Pneumatic | 0.8Mpa |
| Max. lifting weight | 3000KG |
| Total weight | 1500KG |
Parts No.
MB-100 Platform
MB-1 Pulling Tower(include overhead boom)
BB-5 Main Clamp
HP-3 USA Pump (ENERPAC)
WS-1 Wheel Support
MS-1 2-Dimesion Measuring System(with Mitchell Database)
BC-1 Pulling Tools Set(14pcs)
MW-1 Manual Winch
UM-1 User Manual Book
Optional Parts No.
SC-1 Benz Special Clamp
SC-2 BMW Special Clamp
DHC-1103 Big Mouth Pivot
DHC-1110 Big Bending Clamp
DHC-1401 Strut Puller Kit
DHC-1408 Multi-Hole Pulling Plate
EW-1 Electric Winch
