2D Measurement Equipment
2D Measurement Equipment Technical Parameters :
Model |
VMS-1510 |
VMS-2010 |
VMS-2515 |
VMS-320 |
VMS-4030 |
||||||
|
Work Table |
Metal Table Size(mm) |
354x228 |
404x228 |
450x280 |
500x330 |
606x466 |
|||||
Glass Table Size (mm) |
210x160 |
260x160 |
306x196 |
350x280 |
450x350 |
||||||
Moving Stroke (mm) |
150x100 |
200x100 |
250x150 |
300x200 |
400x300 |
||||||
Weight (Kg) |
100 |
110 |
120 |
140 |
240 |
||||||
Dimension WxHxD (mm) |
540x850x560 |
760x900x600 |
970x940x670 |
||||||||
|
Image System
|
Color 1/3’'CCD Video Camera Zoom Lenses: 0.7~4.5× |
||||||||||
Magnification of Video : 40~255× | |||||||||||
Object Field: 71.1mm, LEDsurface lamp plate & LED incident illuminant, light intensity adjustable | |||||||||||
2D Measurement Equipment Features :
1.With RS232 interface, can be connected with computer, adopt specialized measuring software 2D can manage &
output the graphics.
2.Optional print machine, different measurement and scanning system are available
3.Can measure point, line, circle, arc, oval, rectangular and improve the accuracy with the multi point positioning
function
4.Flexible harmonious translation of X,Y,Z axils make the measurement more convenient and efficient.
5.The measuring data can be directly output into Word, Excel & AutoCAD
2D Measurement Equipment Application :
2D Measurement Equipment is widely used to measure the two coordinates in all application areas such as machinery,
electronics, instruments, plastics, etc.
More details please contact Asli sales person ,they will help you find the right precision video testing machine !
...
